Specifications
laser metal carve machine1.Work area: 1500*3000mm
2.Laser power:500w
3.Japan servo motor
4.Water chiller
laser metal carve machine
Applicable
Fiber laser cutting machine is used for cutting stainless steel, mild steel, aluminium alloy, brass etc.
Main parameters:
| Model | metal laser cutting machine |
| Engraving and Cutting Area | 1500*3000 |
| Laser wavelength | 1080nm |
| Rated Laser power | 500-watt RACUS fiber laser |
| X-axis and Y-axis Location accuracy | ±0.01mm |
| X-axis and Y-axis repeat Location accuracy | ±0.01mm |
| Min cutting Line Width | 0.02mm |
| Max. cutting speed | 12m/min |
| Driving system | Japan Panasonic servo motors |
| Transmission way | HIWIN square rail and ball-screw |
| Machine dimension | 4.0m*2.5m*1.7m |
| Support Format and Compatible Software |
PLT,DST,DXF,DWG.CDR, AI, CorelDraw, AutoCAD, Photoshop
|
| Applicable materials | Stainless steel ,Mild steel, Carbon steel, Titanium etc. |
| Whole machine floor space | 4.0×2.5×1.7m |
Main Features:
1. Stable machine body structure: it adopts gantry structure and high-strength cast aluminum alloy X-Axis beam. So it improves the stable of cutting machine and the precision of working.
2. High-performance transmission system: high power Three Japan Panasonic servo motors and Double Taiwan HIWIN ball screw. X and Y axis are equipment with 1500 watts Panasonic servo motors and Z axis is 200 watts. Transmission system is used TAIWAN HIWIN ball-screw which is best in the field. These parts insure the cutting speed and high precision.
3. Advanced laser generator: fiber laser generator imported from UK GSI company with flexible optical path. This kind generator has long lifetime and stable laser power. GSI company has been working on laser device for many years and has a pretty good fame in the world.
4. Highly sensitive cutting head: this cutting machine equiped with original laser-mec cutting head imported from USA. LaserMech cutting head is of good quality and with dynamic focus system. So it can sure the high quality of cutting samples.
Machine parts:
laser metal carve machine Samples:
Factory show
FAQ:
Question:This is the first time I use this kind of machine, is it easy to operate?
There are english manual or teaching video that show how to use machine.If there is
still have any question, please contact us by e-mail / skype/ phone /trademanager online service
at any time.
Question :If machine have any problem after I receive it, how can I do ?
Free parts send to you in machine warranty period if machine have any problem.
If the parts less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.
Question: MOQ ?
the minimum order is 1 set machine, if you order more one time, the price will be better.
Question:D How can I buy this machine from you? ( Very easy and flexible !)
1. Consult us about this product on line or by e-mail.
2. Negotiate and confirm the final price , shipping , payment methods and other terms.
3. Send you the proforma invoice and confirm your order.
4. Make the payment according to the method put on proforma invoice.
5. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
How about your guarantee&warranty service?
1.One year warranty under normal use and we supply maintenance for life for free.
2.24 hours technical support by phone,e-mail,SKYPE,MSN or Remote.
3.Free trainings to make sure you master the operation of laser cutting machine.
4.English operation manual,popular and easy to understand.
CE certificate:
Packing
Shipping
THANKS FOR VISITING THE PRODUCT OF REMAX AND IF YOU HAVE ANY QUESTION PLEASE CONTACE ME!
