VITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver

VITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver thumbnail-1
VITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver thumbnail-2
VITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver thumbnail-3
VITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver photo-1
VITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver photo-2
VITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
VITAI
Model Number:
VT-506M
Contact Supplier Request Quote Chat Now
Quanzhou Vitai Electronics Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
HK or Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name VITAI
Model Number VT-506M
Type Vehicle Mouted
Dimensions 116*85*175mm
Frequency Range 156-163MHz
Storage Channel 88
Talk Range 40 sea miles

VITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver

VITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver

Product Description

 Features:

1. GPS Function

2. Built-In DSC, CH70 Continuous Watch

3. FM 88-108MHz Radio

4. 64 Way-points Memory and Navigation Function

5. 10 Weather Channels and Weather Alert

6. Auto-Record Message

7. Collision Avoidance Alarm Display

8. 10 Weather Channels and Weather Report

9. Priority Scan, Dual-watch and Tri-watch Functions

10. Distress Call, Individual Call, Group Call etc

Technology Specification:

General
(DCS VHF Marine Radio)

Frequency Range

TX:156.025-157.425MHz

RX:156.050-163.275MHz

Channel No.

88 channels

Type of Emission

FM(16K0G3E),DSC(16K0G2B)

Receiving System

Double conversion superheterodyne

Frequency Stabilization

±5ppm

Work Voltage (V)

DC13.8V(±15%)

Operating Temperature

-20°C~+60°C

Antenna Impedance

50Ω

Dimensions(W×H×D)

116×85×175mm

Weight

1350g(±2%)

Transmitter
(  DCS VHF Marine Radio )

RF Power Output

25W/1W

Modulation Limit

±5KHz

Modulation Sensitivity

6mV±3mV

Adjacent Channel Selectivity

≥65dB

TX Audio Distortion

≤5%

Spurious and Harmonic

≤ -65dB

Residual Frequency Modulation

≥40dB

Current Consumption

≤ 8.0A(High power)

≤ 1.5A(Low power)

Input Impedance

2KΩ(Microphone)

Receiver
( DCS VHF Marine Radio )

RX Sensitivity

≤0.2µV(12 dB SINAD)

Band Modulation

≥2*5KHz

Squelch Sensitivity

≥5KHz

Adjacent Channel Selectivity

≥65dB

Intermodulation Anti-interference

≥60dB

Spurious Response Rejection

≥65dB

Max RX Current(mA)

≤1.5A

Audio Output Power

≥3W(8Ω)

Audio Distortion

≤5%

GPS Signal Format

NMEA0183-2.0

Audio Output Impedance

8Ω(Speaker)

All specifications are subject to change without notice due to continuous development.

VITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver
Packaging & Shipping



Item

Qty

VITAI  VT-506M

1

Speaker Mic

1

Mounting Bracket

1

Screws for Mounting Bracket

1

DC Power Cable

1

Spare Fuse

1

Instruction Manual

1





Hong Kong Post
Singapore Post

DHL,UPS,
FedEx,EMS,TNT

Air
Transportation

Sea
Transportation

Sample Order Under 2KG

10-20 working days

5-7 orking days

Inapplicability

Inapplicability

Other Order More Than 2KG

Inapplicability

5-7 working days

7-10 working days

15-30 working days

 Delivery Time and MethodVITAI VT-506M GPS Function VHF156-163MHz IP-X7 Marine FM Transceiver

Our Services

 Why choose us?

1.Gold supplier in Alibaba.

2. Reply your inquiry in 24 working hours.

3. Well trained experienced staff reply all your questions.

4. Customized design is available, OEM are welcomed.

5. Fast delivery to customers all over the world after deposit.

6. 100% QC inspection before shipment.

7. One year warranty for radios, six month for accessories.
