CHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver

CHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver thumbnail-1
CHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver thumbnail-2
CHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver thumbnail-3
CHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver photo-1
CHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver photo-2
CHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
VITAI
Model Number:
VT-507M
Contact Supplier Request Quote Chat Now
Quanzhou Vitai Electronics Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
HK or Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name VITAI
Model Number VT-507M
Type Vehicle Mouted
Dimensions 153*67*152mm
Frequency Range TX:156.025-157.425MHz RX:156.050-163.275MHz
Storage Channel 88
Talk Range 40 sea miles

CHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver

CHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver

Product Description

 Features:

1. Dual-watch and Tri-watch Functions

2. Built-In DSC

3. Favorite Channel Function

4. Aqua quake Draining Function

5.10 Weather Channels and Weather Alert

6. Large Easy –to-See LCD

7. 1meter Depth for 30 Minutes

8. External GPS Receiver Function

9. DSC Call Auto-answer Function

10 Scan Resume Timer

Technology Specification:

General

Frequency Range

TX:156.025-157.425MHz

RX:156.050-163.275MHz

Channel No.

88 channels

Type of Emission

FM(16K0G3E),DSC(16K0G2B)

Frequency Stabilization

±10ppm

Work Voltage (V)

DC13.8V(±15%)

Operating Temperature

-20°C~+60°C

Antenna Impedance

50Ω

Dimensions(W×H×D)

153×67×152mm

Weight

742g

Transmitter

RF Power Output

25W/1W

Maximum Frequency Deviation

±5KHz

Spurious and Harmonic

≤ -70dB(H)

≤ -56dB(L)

Adjacent Channel Selectivity

≥70dB

TX Audio Distortion

≤10%

Current Consumption

≤ 5.5A(High power)

≤ 1.5A(Low power)

Input Impedance

2KΩ(Microphone)

Receiver

RX Sensitivity

≤0.2µV

Squelch Sensitivity

±5KHz

Adjacent Channel Selectivity

≥70dB

Intermodulation Anti-interference

≥70dB

Spurious Response Rejection

≥70dB

Max RX Current(mA)

≤1.5A

Rated Audio Output Power

≥4.5W(10%)

GPS Signal Format

NMEA0183-2.0

Output Impedance

4Ω(Speaker)
CHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine TransceiverCHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver
Packaging & Shipping



Item

Qty

VITAI  VT-507M

1

Speaker Mic

1

Mounting Bracket

1

Screws for Mounting Bracket

1

DC Power Cable

1

Spare Fuse

1

Instruction Manual

1





Hong Kong Post
Singapore Post

DHL,UPS,
FedEx,EMS,TNT

Air
Transportation

Sea
Transportation

Sample Order Under 2KG

10-20 working days

5-7 orking days

Inapplicability

Inapplicability

Other Order More Than 2KG

Inapplicability

5-7 working days

7-10 working days

15-30 working days

 Delivery Time and MethodCHINA SUPPLIER VITAI VT-507M Built-In DSC Aqua Quake Draining Function VHF 156-163MHz IP-X7 Marine Transceiver

Our Services

 Why choose us?

1.Gold supplier in Alibaba.

2. Reply your inquiry in 24 working hours.

3. Well trained experienced staff reply all your questions.

4. Customized design is available, OEM are welcomed.

5. Fast delivery to customers all over the world after deposit.

6. 100% QC inspection before shipment.

7. One year warranty for radios, six month for accessories.

8. Excellent after-sales service.
