Automatic glass Sandblasting Machine for glass and
mirror cutting price
Features:
1. Imported servo motor, CNC controller, rack and rail, advanced control interface make
the machine easy to handle and features high cutting precision.
2. Double mechanical movement bridge system, automatically driving by motor.
3. Imported plastic table surface, bearing and rail are more reliable and endurable.
4. Air float cutting table make it easy loading and unloading glass sheet.
5. Buyer's special specifications are available.
6. Glass breaking machine and Glass loading machine are optional.
Technical specifications of the insulated glass cutting machine:
CUTTING |
JOY-2025 |
JOY-3828 |
JOY-6133 |
JOY-1625 |
Max glass sheet |
2000mm*2500mm |
3700mm* 2700mm |
6100mm* 3300mm |
1600*2500mm |
Overall dimension |
3600mm*3000mm |
4700mm*3500mm |
7600mm*3800mm |
2300*3100mm |
Installed power |
380V----50HZ |
380V---50HZ |
380V----50HZ |
380V----50HZ |
weight |
1000KG |
2500KG |
4300KG |
800kg |
Worktable height |
900mm(±30mm) |
900mm(±30mm) |
900mm(±30mm) |
900mm(±30mm) |
Glass thickness |
2-19mm |
2-19mm |
2-19mm |
2-19mm |
Cutting speed |
140m/mim |
150m/mim |
150m/min |
140m/mim |
Cutting accuracy |
±0.20mm |
±0.25mm |
±0.25mm |
±0.20mm |
Optimization |
OPTIMA |
OPTIMA |
OPTIMA |
OPTIMA |
Transmission |
belts |
belts |
belts |
belts |
Trans speeding |
≥40m/min |
≥40m/min |
≥40m/min |
≥40m/min |
Cutter speeding |
≥160m/min |
≥160m/min |
≥160m/min |
≥160m/min |
0.6pa |
0.6pa |
0.6pa |
0.6pa |
|
Diagonal line |
≤±0.25mm/m |
≤±0.25mm/m |
≤±0.25mm/m |
≤±0.25mm/m |
Area |
9m² |
16m² |
28m² |
7m² |
One year warranty, 24 hours on line service, engineer can go aboard
parter business all over the world
