Glass cutting machine automatic machine for glass and mirror

glass cutting machine

  Glass cutting machine automatic machine for glass and mirror

Glass cutting machine Description:

This automatic CNC-shaped Glass Cutting Machine allows users to cut out any shape of glass with high precision. It can connect with Loading machine to work together. AUTO CAD designed graphs and figures, automatic cutting, with all the cutting data fully computer controlled. The operator can edit the glass size for cutting with computer. The computer can optimize the cutting size, and give out the data for processing, driven the machine to cut glass sheet automatically in high speed and high precision.

1. Use professional computer soft ware and cutting system;

2. Equipped with the OPTIMIZE system, the efficiency of glass reached 92%;

3. Cutting beam was imported from German rack and rail with high precision;

4. Air floatation function;

5. Main parts were imported from brand products. It features high quality and long life;

Technical data:

Max. Cutting size           5000mmX3300mm

Glass cutting thickness      3~19mm

Processing cutting speed    0~160 m/min

Table height:                 910±10mm

Cutting Accuracy for straight:  ≤±0.20 mm/m

for any shape  ≤±0.30 mm/m

Weight                     3800kg

Voltage                     380V 3-phase, 50Hz

Total Power                 9Kw

Overall Dimension           6150×4212×900 mm

Supply air: 5kg/cm²,Stability dry compressed air

One-year after-sales service:

1. We will offer some of the parts for free in the first year. The buyer needs to pay for the shipping cost for the parts. The user needs to send us pictures of the broken one, then we will send out the part they need.

2. In the first year, if the buyer needs our engineers to come to the local to fix some problems of the machine that they cannot fix by themselves; we will send our engineers for free. The buyer needs to pay the flights, housing and meals for the engineers in the local.

3. We will offer our service through email and phones if the buyer needs any help on technical problems.

Wuhan King Suntime CNC Equipment Co.LTD. is a professional manufacturer of industrial CNC equipment,

which loacted in "Optics Valley" , Wuhan city, China. Our company principle is to produce the first class

products, create perfect services. our customers all over the world.

1, How to pay to you ?

T/T inadvance or by Others . We can accept 30% deposit , and balance paid to us before delivery machine to

you .

2, How long is the delivery time?

For standard machines, it would be 15 days; For non-standard machines and customized machines according

to clients specific requirements.

3. I want a size that you don`t make as standard, is this possible?

Absolutely, we can design and manufacture any size our clients require.

4. I am new to CNC, how difficult are your machines to operate?

We help a lot of beginners in CNC, if you have a reasonable knowledge of computers and are willing to spend

a little time learning it is not that bad.We can also offer installation and operator training service upon request.

Clients have to responsible for the expenses on traveling, food and accommodation.

5. How do you send your CNC machine?

They are firstly packaged in wooden case. Usually, we send machine by ship, sometimes, as customer's

requirement, send by air or by train. When the goods arrive at your sea port or destination, you can pick up

goods with the bill of lading we offered. Or we can arrange the cargo agent to send goods to you.

6. How is your waranty and service?

After clients purchased our products, our sales with contact with clients frequently, to help clients solve any

problem regarding to our products. Also, we recommend clients to prepare some spare parts. We can also

send spare parts and wearing parts to clients who need them urgently.

All our CNC router, laser engraving machine, and plasma cutting machines are provided with one year warranty,

 during which some components and parts can be replaced .
