TBC P1004 GEPON ONU

TBC P1004 GEPON ONU thumbnail-1
TBC P1004 GEPON ONU photo-1
Negotiable MOQ: 2 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Tincam
Model Number:
TBC-P1004
Contact Supplier Request Quote Chat Now
Shenzhen Tianbo Communication Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
yantian/shekou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Tincam
Model Number TBC-P1004

Specifications

1: GEPON ONU/ONT
2 :positioned to support any FTTH infrastructure
3: four 100Mbps ethernet port,2*POTS,1*RF

Abiding by IEEE802.3ah,   GEPON ONU P1004-2*VOIP-RF meets relevant requirements of GEPON OUN regulated in Technical Requirements of YD/T1475-2006—Ethernet-Based EPON and China Telecom EPON Technical

Requirements. Through hi-speed EPON access, GEPON ONU P1004-2*VOIP-RF can provide users Internet services and the service of accessing the enterprise network



Technical Parameters



Attributes



P1004-2*VOIP-RF





User trial interfaces

four fixed 10/100M BASE-T auto-adaptable RJ45 interfaces

Management

configuration



arious management modes such as CLI, Web,

SNMP, TELNET and cluster

RMONv1, group 1, group 2, group 3 and group 9

SSHv1/v2

Upgrading the software and the bootrom through

TFTP and FTP

Local or the server’s syslog logs

Command prompt in English or in Chinese

Network testing tools such as ping and traceroute

Debug output

PON interface Type

A 1Gbps transmission rate with downlink and

uplink symmetry

Network coverage diameter: 30 kilometers

of the optical interface: SC/PC

Hi-sensible optical receiver: Not less than -26dBm

Radiation power: 2-7dBm

Security: ONU authentication mechanism

Physical

structure



206.0 mm(W) x 135.5 mm(D) x 41.8 mm(H)

Installation: desktop

Requirements of dust prevention: dust’s diameter

> 5µm; dust concentration ≤3×104 corpuscle/m3

Functions of the  VoIP interface

Interface type: RJ11

Ring flow voltage: 50±10VAC, 30±10H

Supporting MGCP and SIP

Supporting automatic switchover of active software and standby software

Supporting voice encoding/compression

technologies such as G.711 A-Law/u-Law,

G729A/B, G.723.1-5.3/6.3 and G.726

Environment

requirements

Working condition: -5°C~45°C;

5%-95% no condensation

Storage condition: -20°C~70°C;

5%-95% no condensation

CATV RF

75Ω

, F style (CATV connection)

Frequency bandwidth: 47-870MHz

Electricity output level: 17dBuV

Power Source



Type of the power adapter: the on-off power adapter

Input voltage: 110V~240V,50Hz ±5%

Output voltage:12W, 1.5A

Fluctuated range of the input voltage: ±20%

(domestic); ±10% (international)

Fuse: Installing the irrecoverable temperature

fuse (or temperature resistance) at the input terminal

Over-current protection and overvoltage protection

Power consumption: Up to 12W

Standard   IEEE

IEEE 802.3ah

PRC Community Industry Standard (YD/T

1475-2006)

802.1D, Spanning Tree

IEEE 802.1Q, VLAN

IEEE 802.1w, RSTP

Ethernet – II, Ethernet-SNAP

Dielectric

strength



Power source to hull: AC 3000V, lasting one minute

Power source to network port: AC 3000V, lasting

one minute

VLAN

Port-based VLAN

GVRP

IEEE 802.1Q VLAN

Thunder

prevention

Power source: differential mode 2.5KV,

common mode 4KV

Network port: common mode 1KV

QOS

Backpressure flow control (half duplex)

IEEE 802.3x flow control (full duplex)Head Of Line (HOL) prevention mechanism

IEEE p802.1p, CoS

Four transmission queues on each port are

mapped to eight priority values of 802.1p.

WR, SP and FIFO

Rate contro



EMC

GB9254-1998(idt CISPR22:1997)

Reliability



Unidirectional Link Detection (UDLD)

Dying-Gasp





Network security

EEE 802.1x, port-based access control

Supporting the local and remote authentication,

EAP termination or transparent transversal

CHAP and EAP authentication

Limiting the maximum number of users on each

port

Protecting the port

Controlling the storm of packet
