G2513/80W Single head flatbed laser cutting and engraving machine.
Specifications
Application: Laser Cutting and Engraving.
Laser Type: CO2 Reci glass tube.
Cutting Thickness: 0-20mm
Cutting Area: 2500x1300mm
Cutting Speed: 0-60000mm/min
Cooling Mode: Water Cooling
Control Software: CorelDraw, AutoCAD
Graphic Format Supported: AI, PLT, DXF, BMP, GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,PAT,CDT,CLK,DEX,CSL,CMX,WPG,WMF,CGM,SVG.
Certification: CE, ISO, SGS, BV,FDA
Working materials: Non-metal materials
Control System: DSP
Software: Output directly to CorelDraw or AutoCAD.
Data transfer interface: USB cable or USB flash drive(offline).
Work table options: up & down aluminium honeycomb table, slat table.
Power failure: Auto recovery.
Feeding: Through feed of large materials.
Included:
Industrial Chiller
Air assist pump with ease access volume control. (build in)
Red dot pointer. (build in)
Slat Table.
Honeycomb table.
50mm focus lens.
Free software upgrades and manuals via our website.
Many downloadable designs from our website free.
Optional extra:
100W, 150W laser tubes and power supply.
Rotary table.
Advantage above other makes and models:
Our machines print straight from CorelDraw or AutoCAD or our own Laser Work software. Thus no chance for software to be corrupted in the transfer process.
We only make use of an Industrial Chillers, no fish tank pumps and tanks are used for cooling.
Service:
With more than 20 Years' experience in the service industry.
We also carry spares for all our machines.
Features
Industrial chiller
Air assist motor
Laser pointer from back of machine
Slat and honeycomb table
Extractor fan
Software drivers
A pack of extra 2D and 3D designs
No dongle needed.
Unlimited driver installations.
Vat included on all machines prices.
Software
Auto image duplication on full board.
Preview Image cutting path.
Automatically Calculate time to cut job. Easy Bitmap handle for engraving images.
Auto close of curves.
Delete overlap.
Combine curves.
Create smooth curve.
9Point image start position.
Outside or Inside cut compensation.
Cut In/Out for smooth Start/End
