19" Patch Panel Dual 50 Port RJ45 Patch Panel Cat5e Patch Panel
Features
Meets ANSI/TIA/EIA-568-B.2 Category 5e requirements
Meets TIA/EIA TSB-40
Meets ISO/IEC Generic Cabling Standard 11801
Description
Diminished size for mounting in 10" wall mount cabinets
This patch panel is designed for 22 – 26 AWG solid conductors
Height: 1U
Materials
Housing: ABS 94V-0 fiber patch panel
IDC: PC UL94V-0
PCB: FR-4 1.6 mm (0.06") thick, 2 layers
Contacts: 0.35 mm (0.014") phosphor bronze with 1.27 micron (50 microinches) gold plating on contact area
Metal housing: 1.6 mm (0.06") metal thick
Construction characterisic features
Color marking of conductors according to T568B and T568A
Numeral marking on the front side of the panel
Space for additional marking
Color and numeral marking of IDC modules on the rear side of the panel
Hyperline patch-cord usage provides the best connection
110 type punch down tool is used for cable termination
Electrical characteristics
According to UL 1863
Current rating: 1.5 A max
Voltage rating: 150 V
Contact resistance: 20 mOhm
Insulation resistance: 500 MOhm
Dielectric withstand voltage: 1000 V AC RMS, 60Hz/1min
