Name: Dongfeng diesel generator 500kva 50HZ 3 phase generator by famous certification authorithy BV
We are one of the TOP suppliers on ALIBABA and engaged in this industry for
20 years!
1. 12 months warrant
2. CCS,BV certificate
3. heat exchanger
4. top supplier
Dongfeng marine diesel generator general feature
1.Couple with Dongfeng diesel engine and Marathon alternator
2.24V DC start motor
3.Brushless, Self-excited, IP23, insulation class H alternator
4.All qualified generator sets are subjected to a comprehensive performance test which includes 50% load, 75% load, 100%
load,110% load and to check, verify that all control systems, alarm and shut-down protection.
Genset Technical Data
Prime power |
400kW |
Standby power |
440kW |
Rated speed |
1500 RPM |
Output frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V |
Noise dB(A) @7m |
100 |
Engine model |
KTA19-DM |
Alternator model |
MX-H-400-4 |
Advantages
l Stability, reliability and easy-service
l Low operating and maintenance cost
l Widely used, location to meet customer needs
l Easy-installation, easy-operation and maintenance
ENGINE SPECIFICATION
Dongfeng Diesel Engine Technical Data
Engine Model |
KTA19-DM |
Number of Cylinders |
6 cylinders in line |
Cycle |
4 stroke |
Aspiration |
Turbocharged and aftercooled |
Bore×Stroke |
159x 159mm |
Displacement |
19.0 L |
Prime Power/Speed |
448KW/1500 rpm |
Speed Governor |
electrical |
Cooling System |
By heat exchanger |
Fuel Consumption at 100% Load |
204g/KW.h |
Starter Motor |
DC24V |
Alternator specification
Marathon Alternator (standard) Technical Date
Alternator model |
MX-H-400-4 |
Alternator manufacturer |
Marathon |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
400kW |
Rated speed |
1500 RPM |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V(Available with customer requirements) |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
Alternator option:Sunvim ,stamford
Alternator Brand |
Alternator Model |
Phase |
Rated Speed |
Rated Prime Power |
Sunvim |
SVH354 |
3 |
1500RPM |
400 |
Stamford |
HCM534E |
3 |
1500RPM |
400 |
Control System MFKC200AG
All FENGDE marine gensets have a control cubicle (the ENDA MFKC200AG as standard) mounted on a isolated support, which has the following features.
ν Microcomputer digital control, and reliable work
ν Digital display of parameters of diesel engine, and integration of measuring and monitoring
ν Modularization of functional configuration, and integration of product structures
ν Resistance to vibration, humidity, salt mist and high/low temperature
ν Powerful ability to resist interference, convenient installation and use, and high performance-price ratio
ν Remote monitoring of running parameters
ν Automatic zero set of lubricating oil pressure
ν Accumulation of running period of diesel engine
The control module display
ν Lube oil temperature
ν Lube oil pressur
ν Water temperature
ν Engine speed
ν Batter voltage
ν Engine run-time (Hours)
Main introduction of our company as follows:
