HOT SALE 175kw MWM Industrial Diesel Generator

HOT SALE 175kw MWM Industrial Diesel Generator thumbnail-1
HOT SALE 175kw MWM Industrial Diesel Generator photo-1
US$ 2,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
MWM
Model Number:
JGM175GF
Contact Supplier Request Quote Chat Now
Taizhou Fengde Mechanical & Electrical Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name MWM
Model Number JGM175GF
Output Type AC Three Phase
Speed 1500rpm
Frequency 50HZ
Rated Power 175KW
Rated Voltage 400V/230V
Rated Current 315A

MWM industrial diesel generator general feature

1.All qualified generator sets are subjected to a comprehensive performance test which includes 50% load, 75% load, 100% load, 110% load and to check, verify that all control systems, alarm and shut-down protection.

2.Equipped with battery charger and 24V high performance maintenance-free lead-acid starting batteries and connecting cables.

3.Equipped with industrial silencer and flexible exhaust hose.

4.Equipped with 8-hours operation base fuel tank.

5.Equipped with PEOPLE MCCB circuit breaker.

6.Designed to Comply with ISO8528/GB2820.

7.Powered by MWM engine and coupled with Marathon alternator.



Advantage

1.Stability, reliability and easy-service

2.Low operating and maintenance cost

3.Widely used, location to meet customer needs

4.Easy-installation, easy-operation and maintenance



Genset Technical Data



Prime power

175 kW

Standby power

219 kW

Rated speed

1500 RPM

Output frequency

50 Hz

Phase

3

Rated voltage

400 V

Noise dB(A) @7m

100

Engine model

TBD234V6

Alternator model

MP-180-4



Prime Power : Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour period of operation.



Standby Power Rating : The standby power rating is applicable for supplying emergency power for the duration of a utility

power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.



ENGINE SPECIFICATION



MWM Diesel Engine Technical Data



Engine Model

TBD234V6

Number of Cylinders

6

Cylinder arrangement

Cylinders in V type

Cycle

4 Cycle

Aspiration

Turbocharged / After cooled

Bore×Stroke

128 x140 mm

Prime Power/Speed

191KW/1500rpm

Speed Governor

Electronic

Cooling System

Water-cooled , 40℃ Radiator As Standard, 50℃ Is Optional.

Speed Stability (%)

≤5%

Fuel Consumption at 100% Load

220 g/kw.

Starter Motor

DC24V,



Alternator SPECIFICATION

Marathon Alternator Technical Data

Alternator model

MP-180-4

Alternator manufacturer

Marathon

Exciter type

Single bearing, Brushless, Self-excited

Rated output prime power

180 kW

Rated speed

1500 RPM

Rated frequency

50 Hz

Phase

3

Rated voltage

400 V(Available with customer requirements)

Power factor

0.8

Voltage adjust range

≥5%

Voltage regulation NL-FL

≤±1%

Insulation grade

H

Protection grade

IP23





Alternator option: Sunvim,Stamford, Lrroy somer.



Alternator Brand

Alternator Model

Phase

Rated Speed

Rated Prime Power

Sunvim

SV274H1

3

1500RPM

180

Stamford

UCD 274J

3

1500RPM

184

Leroy somer

LSA 46.2 M3

3

1500RPM

180



Control System



Control System HGM6110



All FENGDE gensets have a control cubicle (the smart gen HGM6110 as standard) mounted on a isolated support, which has the following features.



ν Electronic digital control module with monitoring/control facility and warning indicators

ν Automatic shutdown protection

ν Emergency stop button (lock-down type)

ν AC output circuit breaker with over-current protection

ν DC circuit control switch



The control module display



ν Generator voltage

ν Generator voltage

ν Output frequency

ν Engine speed

ν  Battery voltage

ν  Engine run-time (Hours)

ν  Note:

ν  1. The engine coolant temperature displayed by water temperature gauge

ν  2. The engine oil pressure displayed by oil pressure meter

ν  3. Generator current displayed by current meter, to change switch for each phase displayed separately



The control module display for failure information



ν Overspeed / underspeed

ν  Emergency stop

ν  Low oil pressure

ν  High water temperature

ν  Failure to start

ν Battery charger failure



Automatic shutdown



ν Low engine oil pressure

ν  High engine water temperature

ν Overspeed/underspeed

ν  Failure to start after three attempts



Main introduction of our company as follows:
