Help CenterHOT SALE 400kw MWM Industrial Diesel Generator
Related Products
-
HOT SALE 500kw MWM Industrial Diesel GeneratorNegotiableMOQ: 1 Set -
HOT SALE 1000KW MWM Industrial Diesel GeneratorNegotiableMOQ: 1 Set
-
HOT SALE 1700KW MWM Industrial Diesel GeneratorNegotiableMOQ: 1 Set
-
BEST PRODUCT OF 150KW MWM MARINE DIESEL GENERATORUS$ 2,000 - 200,000MOQ: 1 Set
-
HOT SALE 200KW MWM Marine Diesel Generator From ChinaNegotiableMOQ: 1 Set
MWM industrial diesel generator general feature
1.All qualified generator sets are subjected to a comprehensive performance test which includes 50% load, 75% load, 100% load, 110% load and to check, verify that all control systems, alarm and shut-down protection.
2.Equipped with battery charger and 24V high performance maintenance-free lead-acid starting batteries and connecting cables.
3.Equipped with industrial silencer and flexible exhaust hose.
4.Equipped with 8-hours operation base fuel tank.
5.Equipped with PEOPLE MCCB circuit breaker.
6.Designed to Comply with ISO8528/GB2820.
7.Powered by MWM engine and coupled with Marathon alternator.
Advantage
1.Stability, reliability and easy-service
2.Low operating and maintenance cost
3.Widely used, location to meet customer needs
4.Easy-installation, easy-operation and maintenance
Genset Technical Data
Prime power |
400 KW |
Standby power |
500 KW |
Rated speed |
1500 RPM |
Output frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V |
Noise dB(A) @7m |
100 |
Engine model |
TBD234V12 |
Alternator model |
MP-400-4A/S |
Prime Power : Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour period of operation.
Standby Power Rating : The standby power rating is applicable for supplying emergency power for the duration of a utility
power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
ENGINE SPECIFICATION
MWM Diesel Engine Technical Data
Engine Model |
TBD234V12 |
Number of Cylinders |
12 |
Cylinder arrangement |
Cylinders in V type |
Cycle |
4 Cycle |
Aspiration |
Turbocharged / After cooled |
Bore×Stroke |
128 x140 mm |
Prime Power/Speed |
444KW/1500rpm |
Speed Governor |
Electronic |
Cooling System |
Water-cooled , 40℃ Radiator As Standard, 50℃ Is Optional. |
Speed Stability (%) |
≤5% |
Fuel Consumption at 100% Load |
220 g/kw.h |
Starter Motor |
DC24V, |
Alternator SPECIFICATION
Marathon Alternator Technical Data
Alternator model |
MP-400-4A/S |
Alternator manufacturer |
Marathon |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
400 kW |
Rated speed |
1500 RPM |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V(Available with customer requirements) |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
Alternator option: Sunvim,Stamford, Lrroy somer.
Alternator Brand |
Alternator Model |
Phase |
Rated Speed |
Rated Prime Power |
Sunvim |
SV354D |
3 |
1500RPM |
400 |
Stamford |
HCI 444F |
3 |
1500RPM |
400 |
Leroy somer |
LSA 47.2 M7 |
3 |
1500RPM |
400 |
Control System
Control System HGM6110
All FENGDE gensets have a control cubicle (the smart gen HGM6110 as standard) mounted on a isolated support, which has the following features.
ν Electronic digital control module with monitoring/control facility and warning indicators
ν Automatic shutdown protection
ν Emergency stop button (lock-down type)
ν AC output circuit breaker with over-current protection
ν DC circuit control switch
The control module display
ν Generator voltage
ν Generator voltage
ν Output frequency
ν Engine speed
ν Battery voltage
ν Engine run-time (Hours)
ν Note:
ν 1. The engine coolant temperature displayed by water temperature gauge
ν 2. The engine oil pressure displayed by oil pressure meter
ν 3. Generator current displayed by current meter, to change switch for each phase displayed separately
The control module display for failure information
ν Overspeed / underspeed
ν Emergency stop
ν Low oil pressure
ν High water temperature
ν Failure to start
ν Battery charger failure
Automatic shutdown
ν Low engine oil pressure
ν High engine water temperature
ν Overspeed/underspeed
ν Failure to start after three attempts
Main introduction of our company as follows:
