Specifications
1.truck mounted generator sets2.ISO,CE certificate
3.reliable performance
4.global service for 12 month
1. truck mounted generator sets general feature :
Besides all performances of Silent Type Gen Sets, JG Silent Type Gen Sets with Trailer has
Advantages as follows:
Equipped armor plate spring of structure poised;
The trailer adopt the adjustable- height bolted towed rack, which is suitable for different height trailer;
Have mechanical underprops at each corner of the trailer. Inertial traveling brake, station brake & disengage emergency brake between trailer and tractor
With turning lamp, brake indicator light and standard BNC connector plugs for back lamp
We are the top VIP supplier on Alibaba,
authorized by famous certification authority-BV ( Bureau Veritas ).
2. Cummins engine Technical Data:
Engine Model |
6CTA8.3-G2 |
Configuration |
4 cycle , 6 cylinders in line |
Aspiration |
Turbocharged after water-cooled |
Bore×Stroke |
114 x135 mm |
Rated speed |
1500rpm |
Displacement |
8.3L |
Compression Ratio |
16.5:1 |
Prime Power |
163KW |
Speed Governor |
electrical |
Cooling System |
Water-cooled , 40°C Radiator As Standard, 50°C Is Optional. |
Speed Stability (%) |
≤5% |
Fuel Consumption at 100% Load |
210g/kw.h |
Starter Motor |
DC24V |
Marathon alternator echnical Data:
Alternator model |
MP-150-4 |
Alternator manufacturer |
Marathon |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
150 kW |
Rated speed |
15000RPM |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V(Available with customer requirements) |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
3.Warranty:
Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.
4. Document:
1) Alternator operation and maintenance manual 1PC
2)Engine operation and maintenance manual 1PC
3)Generator Overall drawings of the set 1PC
4)Electrinic system drawing 1PC
5)Bench test 1PC
6)Packing list 1PC
5.picture of control system:
photos for reference
factory picture for reference
silent type for reference
container picture
