Fast Delivery 40kw Silent Diesel Generators With CE,ISO

US$ 9,500 - 25,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Model Number:

JGC40GF

Taizhou Fengde Mechanical & Electrical Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name JG

Model Number JGC40GF

Output Type AC Three Phase

Speed 1500rpm/1800rpm

Frequency 50hz/60hz

Rated Power 40kw

Rated Voltage 440v/440v

Rated Current 72A

Specifications

1.40kw silent diesel generators
2.global service for 12 month
3.ISO,CE certificate
4.75dB at the distance of 7 meters

1. 40kw silent diesel generators general feature:

1) Output range: 40kw(50kVA)

2) Engine model: Cummins

3) Alternator: Stamford, Marathon series

We are the top VIP supplier on Alibaba ,

authorized by famous certification authority-BV ( Bureau Veritas ).

2.Cummins Engine parameter:

Engine Model	4BTA3.9-G2
Configuration	4 cycle , 4 cylinders in line
Aspiration	Turbocharged after water-cooled
Bore×Stroke	102 x120 mm
Rated speed	1500rpm
Displacement	3.9 L
Compression Ratio	16.5:1
Prime Power	50KW
Speed Governor	electrical
Cooling System	Water-cooled , 40°C Radiator As Standard, 50°C Is Optional.
Speed Stability (%)	≤5%
Fuel Consumption at 100% Load	216g/kw.h
Starter Motor	DC24V,

Stamford Alternator technical data:

Alternator model	UCI224E
Alternator manufacturer	Stamford
Exciter type	Single bearing, Brushless, Self-excited
Rated output prime power	45 kW
Rated speed	1500 RPM
Rated frequency	50 Hz
Phase	3
Rated voltage	400 V(Available with customer requirements)
Power factor	0.8
Voltage adjust range	≥5%
Voltage regulation NL-FL	≤±1%
Insulation grade	H
Protection grade	IP23
