Specifications
1.diesel generator 120 kva2.ISO,CE,BV certificate
3.global service for 12 month
4.EIAPP(Nox) certificate
1. diesel generator 120 kva general feature:
1.Coupled with Cummins diesel engine and Stamford Or Marathon alternator
2.24V DC start motor and storage battery
3..Brushless, Self-excited, IP23, insulation class H alternator
4.40°C radiator as standard, 50°C is optional
5.Key start panel control system as standard, digital auto-start panel is optional
6.Optional open type or silent type
7.All generator sets are gone through rigorous testing before being released to the market place, including 50% load, 75% load, 100% load , 110% load and all protection function (overspeed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)
We are the top VIP supplier on Alibaba ,
authorized by famous certification authority-BV ( Bureau Veritas ).
2. Technical Data:
Cummins Diesel Engine Technical Data
Engine Model |
6BTA5.9-G2 |
Configuration |
4 cycle , 6 cylinders in line |
Aspiration |
Turbocharged after water-cooled |
Bore×Stroke |
102 x120 mm |
Rated speed |
1500rpm |
Displacement |
5.9 L |
Compression Ratio |
17.5:1 |
Prime Power |
100KW |
Speed Governor |
electrical |
Cooling System |
Water-cooled |
Speed Stability (%) |
≤5% |
Fuel Consumption at 100% Load |
211g/kw.h |
Starter Motor |
DC24V, |
Marathon Alternator Technical Data
Alternator model |
SV274 |
Alternator manufacturer |
Sunvim |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
100 kW |
Rated speed |
1500 rpm |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
3.Warranty:
Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.
4.Certificate & Document:
|
a. Alternator operation and maintenance manual CCS certificate |
1PC 1PC |
|
b. Engine operation and maintenance manual CCS certificate EIAPPcertificate |
1PC 1PC 1PC |
|
c. Generator CCS certificate Overall drawings of the set ELECTRINIC SYSTEM DRAWING Bench test Packing list |
1PC 1PC 1PC 1PC 1PC |
|
d. Control panel CCS certificate operation and maintenance manual |
1PC 1PC |
5.picture of control system and factory:
