Direct Sale 400kw Containerized Generator

Name: Direct Sale 400kw Containerized Generator
Brand: JiangGuang
SKU: 103727101
Availability: InStock

US$ 8,000 - 10,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

JiangGuang

Model Number:

JGC400GF

Taizhou Fengde Mechanical & Electrical Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name JiangGuang

Model Number JGC400GF

Output Type AC Three Phase

Speed 1500RPM

Frequency 50HZ

Rated Power 400KW

Rated Voltage 230/400V

Rated Current 720A

Specifications

containerized generator
1/CE certificate
2/ISO9001:2000 certificate
3/CCS certificate
4/OEM manufactory

We are the top VIP supplier on Alibaba !!

Authorized by famous certification authority-BV ( Bureau Veritas ) !!

containerized generator
1/CE certificate
2/ISO9001:2000 certificate
3/CCS certificate
4/OEM manufactory

1.Main technical data of gensets
1.1	Model	JG400GF
1.2	Prime power	400KW/500KVA
1.3	Prime voltage	230/400V
1.4	Speed	1500 rpm
1.5	Weight	3800kg
1.6	Overall dimension	3600×1500×2350mm (just for reference)
2.Main technical data of engine
2.2	Model	KTA19-G4
2.3	Prime power	448KW/560KVA
2.4	Governor type	Electronic
2.5	Configuration	4 cycle , 6 cylinder in line
2.6	Air Intake System	Tubocharged/ Aftercooled
2.7	Bore/Stroke	159×159 mm
2.8	Displacement	19 L
2.9	Starting method	Electric
2.10	Compression ratio	14.5:1
2.11	Fuel consumption	196g/kw.h
3. Main technical data of alternator
Alternator is selected the new type brushless alternator designed by US Marathon Electric, which has a unique design, advanced structure, small size, light weight, excellent performance, reliable running and easy-to-use operation.
3.1	Brand	MARATHON
3.2	Model	MX-400-4
3.3	Prime power	400KW/500KVA
3.4	Configuration	Brushless , self-exciting
3.5	Prime voltage	230V/400V
3.6	Frequency	50 HZ
3.7	Power factor	0.8(lagging)
3.8	Phase/wire	3 phase 4 wires
3.9	Isolation	H

Seletion table

Power factor 0.8(delay) Frequency/Speed 50Hz/1500rpm
Model	Rated Power		Rated Current A	Engine Model	Overall dimension (L×W×H)mm	Weight Kg
Model	KW	KVA	Rated Current A	Engine Model	Overall dimension (L×W×H)mm	Weight Kg
JG20GFC	20	25	36	4B3.9-G2	1850×850×1300	780
JG30GFC	30	38	54	4BT3.9-G2	1850×850×1300	850
JG50GFC	50	63	90	4BTA3.9-G2	1850×850×1300	1100
JG75GFC	75	94	135	6BT5.9-G2	2050×850×1500	1450
JG100GFC	100	125	180	6BTA5.9-G2	2050×850×1500	1550
JG140GFC	140	175	252	6CTA8.3-G2	2400×950×1500	2600
JG150GFC	150	188	270	6CTA8.3-G2	2400×950×1500	2650
JG200GFC	200	250	360	6LTAA8.9-G2	2500×1000×1600	2900
JG200GFC	200	250	360	NT855-GA	3050×1050×1900	2700
JG220GFC	220	275	396	NTA855-G1	3050×1050×2000	2750
JG250GFC	250	313	450	NTA855-G2	3050×1050×2000	2850
JG300GFC	300	375	540	NTAA855-G7	3050×1050×2000	3100
JG360GFC	360	450	648	KTA19-G3	3600×1500×2350	3600
JG400GFC	400	500	720	KTA19-G4	3600×1500×2350	3800
JG440GFC	440	550	792	KTAA19-G6	3600×1500×2350	4600
JG450GFC	450	625	900	KTAA19-G7	3600×1500×2350	4700
JG500GFC	500	625	900	KTA38-G	4800×1800×2350	7300
JG600GFC	600	750	1080	KTA38-G2	4800×1800×2350	7500
