Help Center64kw (80kva) Shangchai Marine Diesel Generator With Competitive Price
Related Products
-
90kw Marine Diesel Generator With Competitive PriceUS$ 8,000 - 12,000MOQ: 1 Set -
ZC&CCS Approved 30Kw-300Kw Diesel Generators Powered by Yuchai Marine EnginesNegotiableMOQ: 1 Set
-
ZC&CCS Approved 30Kw-300Kw Yuchai Diesel GeneratorNegotiableMOQ: 1 Set
-
BV,CCS Approved 120kw Shangchai MarineUS$ 6,500 - 8,500MOQ: 1 Set
-
Shangchai Series Diesel Generating Set,shangchai Generator SetsUS$ 8,000 - 15,700MOQ: 1 Set
Specifications
marine diesel Generator1.Class Certificate
2.More than 10 years manufacturing experience
3.Global service for 1 y
4.Steady
1.Class Certificate
2.More than 10 years manufacturing experience
3.Global service for 1 y
4.Steady
marine diesel
Genset Main Technical Data
3-PH, 50Hz@1500RPM, 400/230V (Also Can Be Made According To Customers’ Special Requirements)
Voltage |
HZ |
Phase |
P.F |
Output (KW) |
400/230V |
50 |
3 |
0.8 |
64 |
Shangchai Diesel Engine
Technical Data
Engine Model |
6135Caf |
Number of Cylinders |
6 cylinders in line |
Cycle |
4 stroke |
Aspiration |
Natural Aspirate |
Bore×Stroke |
135 x140 mm |
Displacement |
12.0 L |
Prime Power/Speed |
90KW/1500rpm, |
Speed Governor |
Mechanical / Electrical |
Cooling System |
By heat exchanger |
Fuel Consumption at 100% Load |
205 g/kw.h |
Starter Motor |
DC24V, |
Alternator |
AC24V |
Marathon Alternator (Standard)
Technical Data
Alternator Model |
MP-H-64-4 |
Prime power |
64KW |
Frequency/speed |
50HZ/1500rpm |
Exciter type |
Brushless, Self-excited |
Power factor |
0.8 |
Insulation Grade |
H |
Protection Grade |
IP23 |
Phase / wire |
3 phase 4 wires |
Control System HGM6110
All FENGDE gensets have a control cubicle (the smart gen HGM6110 as standard) mounted on a isolated support, which has
the following features.
n Electronic digital control module with monitoring/control facility and warning indicators
n Automatic shutdown protection
Emergency stop button (lock-down type)
n AC output circuit breaker with over-current protection
n DC circuit control switch
The control module display
n Generator voltage
n Generator voltage
n Output frequency
n Engine speed
n Battery voltage
n Engine run-time (Hours)
n Note:
n 1. The engine coolant temperature displayed by water temperature gauge
n 2. The engine oil pressure displayed by oil pressure meter
n 3. Generator current displayed by current meter, to change switch for each phase displayed separately
The control module display for failure information
n Overspeed / underspeed
n Emergency stop
n Low oil pressure
n High water temperature
n Failure to start
n Battery charger failure
Automatic shutdown
n Low engine oil pressure
n High engine water temperature
n Overspeed/underspeed
n Failure to start after three attempts
marine diesel
