Specifications
Huadong 85KW marine diesel genset1)CCS/BV/DNV/GL class certificate
3)1 year warranty
Huadong 85KW marine diesel genset
CCS class certificate
Genset Main Technical Data
3-PH, 50Hz@1500RPM, 400V (Also Can Be Made According To Customers’ Special Requirements)
Voltage |
HZ |
Phase |
P.F (COS) |
Output (KW) |
400V |
50 |
3 |
0.8 |
85 |
Huadong Diesel Engine
Technical Data
Engine Model |
6105AZLCD |
Number of Cylinders |
6 cylinders in line |
Cycle |
4 stroke |
Bore×Stroke |
105 x125 mm |
Displacement |
9.7 L |
Prime Power / speed |
110KW / 1500rpm |
Speed Governor |
electrical |
Cooling System |
By heat exchanger |
Fuel Consumption at 100% Load |
224 g/kw.h |
Starter Motor |
DC24V, |
Sunvim Alternator (Standard)
Technical Data
Alternator Model |
SVH274 |
Prime power |
90KW |
Frequency/speed |
50HZ/1500rpm |
Exciter type |
Brushless, Self-excited |
Power factor |
0.8 |
Insulation Grade |
H |
Protection Grade |
IP23 |
Phase / wire |
3 phase 4 wires |
Control Panel
Model |
MFKC200AG |
|
*Microcomputer digital control, and reliable work; *Digital display of parameters of diesel engine, and integration of measuring and monitoring; *Modularization of functional configuration, and ntegration of product structures; *Resistance to vibration, humidity, salt mist and high/low temperature; *Powerful ability to resist interference, convenient installation and use, and high performance-price ratio; *Remote monitoring of running parameters; *Automatic zero set of lubricating oil pressure *Accumulation of running period of diesel engine.
| |
