Specifications
650kw diesel generator1/CE certificate
2/ISO9001:2008
3/10 years manufacturing experience
4/Global service for 12 months
We are the top VIP supplier on Alibaba ,
authorized by famous certification authority-BV ( Bureau Veritas )
650kw diesel generator
1/CE certificate
2/ISO9001:2008
3/10 years manufacturing experience
4/Global service for 12 months
Genset Technical Data | |
Prime power |
650kW |
Standby power |
715kW |
Rated speed |
1500 RPM |
Output frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V |
Noise dB(A) @7m |
100 |
Engine model |
4006-23TAG2A |
Alternator model |
MX-650-4 |
Prime Power : Prime power is available for an unlimited number of annual hours in variable load application, in accordance
with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour period of operation.
Standby Power Rating : The standby power rating is applicable for supplying emergency power for the duration of a utility
power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
Perkins Diesel Engine Technical Data
Engine Model |
4006-23TAG3A |
Configuration |
4 cycle , 6 cylinders in line |
Aspiration |
Turbocharged air to air cooled |
Bore×Stroke |
160x190 mm |
Rated speed |
1500rpm |
Displacement |
22.921 L |
Compression ratio |
13.6:1 |
Prime Power |
679KW |
Speed Governor |
Electronic |
Cooling System |
water-cooled |
Speed Stability (%) |
≤5% |
Fuel consumption |
210 g/kw.h |
Starter Motor |
24V |
Marathon Alternator Technical Data
Alternator model |
MX-650-4 |
Alternator manufacturer |
Marathon |
Exciter type |
Single bearing, Brushless, Self-excited |
Rated output prime power |
650kW |
Rated speed |
1500 RPM |
Rated frequency |
50 Hz |
Phase |
3 |
Rated voltage |
400 V(Available with customer requirements) |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation grade |
H |
Protection grade |
IP23 |
Alternator option: Sunvim,Stamford, Lrroy somer.
Alternator Brand |
Alternator Model |
Phase |
Rated Speed |
Rated Prime Power |
Sunvim |
SV404C |
3 |
1500RPM |
650 |
Stamford |
LV1634C |
3 |
1500RPM |
650 |
Leroy somer |
LSA 49.1 M75 |
3 |
1500RPM |
650 |
Control System HGM6110
All FENGDE gensets have a control cubicle (the smart gen HGM6110 as standard) mounted on a isolated support, which has
the following features.
n Electronic digital control module with monitoring/control facility and warning indicators
n Automatic shutdown protection
n Emergency stop button (lock-down type)
n AC output circuit breaker with over-current protection
n DC circuit control switch
The control module display
n Generator voltage
n Generator voltage
n Output frequency
n Engine speed
n Battery voltage
n Engine run-time (Hours)
n Note:
n 1. The engine coolant temperature displayed by water temperature gauge
n 2. The engine oil pressure displayed by oil pressure meter
n 3. Generator current displayed by current meter, to change switch for each phase displayed separately
The control module display for failure information
n Overspeed / underspeed
n Emergency stop
n Low oil pressure
n High water temperature
n Failure to start
n Battery charger failure
Automatic shutdown
n Low engine oil pressure
n High engine water temperature
n Overspeed/underspeed
n Failure to start after three attempts
The control modules option
