Specifications
Weifang Huadong Diesel Gensets 100KW/125KVA1.CE Certificate
2.ISO9001:2008
3.Delivery: 12 working days
Weifang Huadong Diesel Gensets
Huadong diesel genset/ generator set
1.Main technical data of gensets | ||
1.1 |
Model |
JG100GF |
1.2 |
Prime power |
100KW/125KVA |
1.3 |
Prime voltage |
230/400V |
1.4 |
Speed |
1500 rpm |
1.5 |
Weight |
1550kg |
1.6 |
Overall dimension |
2050×850×1500mm (just for reference) |
2.Main technical data of engine | ||
| ||
2.1 |
Brand |
Weifang Huadong |
2.2 |
Model |
6105AZLD |
2.3 |
Prime power |
110KW/137.5KVA |
2.4 |
Governor type |
Electronic |
2.5 |
Configuration |
4 cycle , 6 cylinder in line |
2.6 |
Air Intake System |
Tubocharged/After cooler |
2.7 |
Bore/Stroke |
102×120 mm |
2.8 |
Displacement |
5.9 L |
2.9 |
Starting method |
Electric |
2.10 |
Compression ratio |
17.0:1 |
2.11 |
Fuel Consumption |
211g/kw.h |
3. Main technical data of alternator | ||
| ||
3.1 |
Brand |
Mindong |
3.2 |
Model |
TFX-100 |
3.3 |
Prime power |
100KW/125KVA |
3.4 |
Configuration |
Brushless , self-exciting |
3.5 |
Prime voltage |
230V/400V |
3.6 |
Frequency |
50 HZ |
3.7 |
Power factor |
0.8(lagging) |
3.8 |
Phase/wire |
3 phase 4 wires |
3.9 |
Isolation |
H |
