Specifications
20KW(25KVA) Huadong diesel generating setEngine model:K4100D,Alternator model:Kaijieli
Diesel genset,diesel generating set
20KW(25KVA) Huadong diesel generating set
Engine model:K4100D,Alternator model:Kaijieli
Diesel genset,diesel generating set
Generator Model |
JG20GF |
Rated Power |
20KW/25KVA |
Standby Power |
22KW/28KVA |
Voltage |
230V/400V |
Frequency |
50HZ/1500 rpm |
Power factor |
0.8 |
Dimensions |
2000x800x1300mm |
Weight |
850kg |
Engine |
|
Manufacturer |
Huadong |
Model |
K4100D |
Configuration |
4 cycle,4 cylinder in Line |
BorexStroke |
100x115mm |
Aspiration |
Turbocharged |
Cooling Method |
Water cooled |
Rated Power |
30KW/38KVA |
Standby Power |
33KW/42KVA |
Rated Speed |
1500rpm |
Compression Ratio |
19:1 |
Fuel consumption |
≤258.4g/kw.h |
Starting Method |
Electrical start |
Alternator |
|
Manufacturer |
Kaijieli |
Model |
TWG184F |
Rated Power |
20KW/25KVA |
Standby Power |
22KW/28KVA |
Voltage |
230V/400V |
Frequency & speed |
50HZ / 1500rpm |
Power factor |
0.8 |
Design |
Brushless,self-exciting |
Rotor |
Single bearing |
Phase and wire |
3 phase and 4 wires |
Excited type |
Self Excited |
Isolation level |
H/H |
Protection class |
IP21 |
Rotation(seen from flywheel end) |
clockwise |
