14.5kva Cheap Portabe Diesel Generator for Sale

Name: 14.5kva Cheap Portabe Diesel Generator for Sale
Brand: Boomaster
SKU: 103715443

US$ 1,999 - 19,999 MOQ: 1 Set

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Boomaster

Model Number:

BM -15

Elephant Tech Fuzhou Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Boomaster

Model Number BM -15

Output Type AC Three Phase

Speed 1500/1800rpm

Frequency 50HZ

Rated Power 14.5KVA

Rated Voltage 230/400V

Rated Current 21A

Specifications

14.5kva cheap portabe diesel generator for sale
1)water-cooled
2)Delivery Time:20 Days
3)Payment:L/C,T/T

14.5kva cheap portabe diesel generator for sale

Product Overview

1) Brand-new engine,w/start motor.

2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR.

3) Auto control panel with LCD display.

4) Engine mounted battery-charging alternator,Genset with battery charge of main supply.

5) Circuit Breaker,Exhaust Silencer.

6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard.

7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable.

8) Skid-mounted bottom 8 hours fuel tank.

9) Extemal recessed emergency stop button for extra safety.

10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system.

Genset Specification
Genset Model	BM16YM5(50Hz)
Prime Power(Kva/Kw)	11.6Kw/14.5Kva(50Hz)
Engine Model	YANMAR 3TNV84T
Alternator Model	PI044G(50Hz)
Speed Control type	Centrifugal-all speed governor
Phase	Three
Fuel Tank Capacity	50 L
System Voltage	12V
Frequency	50/60 Hz
Fuel injection pump	Bosch in-line, Yanmar made
Emission level	Stage 4
Dimension(LWH mm)
Open Type	14607301170
Silent Type	18007401150

Engine Detail
Model	YANMAR 3TNV84T
Maximum output(kw)	15.8KW(50Hz)
Number of Cylinders	3
Aspiration	Naturally aspirated
Cycle	4
Fuel Type	Diesel
Combustion Type	Indirect Injection
Cooling Type	Water cooled
Coolant Capacity	2liter
Lubrication Capacity	6.7 liter
Bore*Stroke	84*90mm
Displacement	1.496 L
Compression ratio	19:01

Alternator Detail
Model	PI044G(50Hz)
Insulation	Clase"H"
Execitation Type	Self-excitation
Protection class	IP23
