Specifications
Electric diesel generator for sale by deutz power1.Duetz power
2.Stamford alternator
Electric diesel generator for sale by deutz power
Genset specification
Genset model |
BD-60 |
Prime power(kw/kva) |
48/60 |
Standby power(kw/kva) |
53/66 |
Engine model |
TD226B-4D Deutz |
Alternator model |
STG224E |
dimension(L*W*H)mm |
2200*900*1550 |
Weight(kgs) |
1000 |
Engine details
Engine |
TD226B-4D |
12h Rate output(kw) |
60 |
Aspiration & Cooling |
Turbo |
Cylinders Capacity(Lt) |
4 |
In Line | |
Engine Speed(RPM) |
1500 |
Bore & Stroke(mm*mm) |
105*120 |
Compression Ratio |
15.5 |
Governor |
M/E |
Fuel consumption(g/kwh) |
208 |
Lub-oil Capacity(Litre) |
7.75 |
Coolant Capacity(Litre) |
25 |
Air Combustion(m3/min) |
3.5 |
Exhaust Air Flow(m3/min) |
168 |
Alternator details
Model |
STG224E |
Rater power |
48kw |
Exciting Style |
Brushless,self-exciting,self-radiating |
Voltage-Regulating System |
AVR automatic regulation |
Insulation class |
H |
Protection grade |
IP22 |
Regulating rate of steady voltage |
±0.5% |
Regulating rate of transient frequency |
±0.5% |
Regulating rate of transient frequency |
≤3S |
Products photo:
Factory:
Packing:
Exhibition:
Cetificate:
