32kw/40kva Yuchai Engine Electric Generator
US$ 3,399 - 3,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
BOOMASTER, Yuchai
Model Number:
BQ-40
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
20kw Yuchai Diesel Generator SoundproofUS$ 2,400 - 3,200MOQ: 1 Set -
50kw Yuchai Diesel Generator Soundproof for SaleUS$ 4,200 - 5,000MOQ: 1 Set
-
100kw Yuchai Engine Diesel GeneratorUS$ 6,400 - 7,700MOQ: 1 Set
-
80kw Yuchai Engine Electricity GeneratorUS$ 5,700 - 7,200MOQ: 1 Set
-
64kw Yuchai Generator Powered by Diesel EngineUS$ 5,200 - 6,500MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
BOOMASTER, Yuchai
Model Number
BQ-40
Output Type
AC Three Phase
Speed
1500rpm
Frequency
50/60Hz
Rated Power
40KVA
Rated Voltage
230/400V
Rated Current
57.7A
Specifications
32kw/40kva yuchai engine electric generator1.Yuchai engine
2.CE/EPA/ISO9001
3.Warranty:12months
32kw/40kva yuchai engine electric generator:
| Product Overview | |
| 1) Brand-new engine,w/start motor. | |
| 2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR. | |
| 3) Auto control panel with LCD display. | |
| 4) Engine mounted battery-charging alternator,Genset with battery charge of main supply. | |
| 5) Circuit Breaker,Exhaust Silencer. | |
| 6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard. | |
| 7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable. | |
| 8) Skid-mounted bottom 8 hours fuel tank. | |
| 9) Extemal recessed emergency stop button for extra safety. | |
| 10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system. | |
| Genset Specification | |
| Genset Model | BYC-40 |
| Prime Power(Kva/Kw) | 32KW/40KVA |
| Structure type | Open/Silent |
| Dba"@7m | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
| Engine Model | YC4D60 |
| Alternator Model | STG184J |
| DimensionL*W*H(mm) | |
| Open Type | 1982*850*1250 |
| Weight | 950 |
| Silent Type | 2082*950*1350 |
| Weight(Kg) | 1000 |
| Engine Detail | |
| Engine Brand | Yuchai Diesel engine |
| Model | YC4D60 |
| Engine speed | 1500rpm |
| Engine power | |
| …………Standby power | 35KW |
| …………Prime power | 32KW |
| Type | 4cycle,in-line,4-cylinder |
| Aspiration | Turbocharged, |
| Governor | electrical |
| Bore*Stroke | 108*115mm |
| Displacement | 4.214 Litres |
| Compression ratio | 17.5:1 |
| Alternator Detail | |
| Manufacturer | Fuzhou Boomaster Power Co.,Ltd |
| Model | STG184J |
| Output power | 32KW |
| Number of phase | 3 |
| Power factor(Cos Phi) | 0.8 |
| Altitude | ≤1000m |
| Overspeed | 2250rpm |
| Number of Pole | 4 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | ±0.5% |
| Sustained short circuit current | 300%(3IN):10s |
| Total haarmonics (TGH/THC) | <4% |
| Wave form:Nema=TIF | <50 |
| Wave form:I.E.C=THF | <2% |
| Bearing | single |
| Coupling | Direct |
Generator soundproof/Silent and canopy box:
Ø 8 hours’ base fuel tank
ØExcellent ventilation
ØBlack finish stainless steel locks and hinges
ØZinc plated or stainless steel fasteners
ØBody made from steel components treated with polyester powder coating
ØTwo large doors on either side
ØRadiator fill access plate
ØFully guarded cooling fan and battery charging alternator
ØFuel fill and battery access via lockable access doors
ØEmergency stop button on canopy exterior
ØLube oil drain and radiator drain to exterior
ØControl panel viewing window
ØLifting points on base frame
Ø1m<80DBA / 7m<70DBA
Generator set warranty and maintenance:
ØDo the full power load test for five hours before package.
ØOne year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.
ØAfter expiration, we provide spare parts maintenance with low price.
Silent chinese engine diesel generator:
Our factory:
Exhibition:
Certificates:
