Home > Industrial Equipment & Components > Boiler & Furnace > Boiler > Horizontal Chain Grate Coal & Biomass Fired Thermal Oil Heater With Automatical Control
Horizontal Chain Grate Coal & Biomass Fired Thermal Oil Heater With Automatical Control
US$ 5,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Natural Circulation
Usage:
Industrial
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Best Sale Safe Operation Industrial Vertical Thermal Oil HeaterUS$ 9,000 - 90,000MOQ: 1 Set -
Solid Fuel Fired Charcoal Fired Manual Thermal Oil Boiler With Friendly EnviromentUS$ 20,000 - 500,000MOQ: 1 Set
-
Diessel and Natural Gas Dual Fuel Fired Thermal Oil Boiler With Italy BurnerUS$ 20,000 - 500,000MOQ: 1 Set
-
Horizontal Diesel Gas Combi Boiler Thermal Oil BoilerUS$ 10,000 - 150,000MOQ: 1 Set
-
Industrial Boiler, Thermal Oil Heater, Biomass BoilersUS$ 10,000 - 200,000MOQ: 1 Set
Condition
New
Type
Natural Circulation
Usage
Industrial
Structure
Fire Tube
Pressure
Low Pressure
Style
Horizontal
Fuel
Coal-fired
Place of Origin
Shandong, China
Brand Name
EPCB
Model Number
YLW type
Output
Other, heat transfer oil
Dimension(L*W*H)
Customization
Weight
5~50ton
Certification
GB,ASME, CE, GOST
After-sales Service Provided
Engineers available to service machinery overseas
Horizontal Chain Grate Coal & biomass fired thermal oil heater with automatical control
Product Description
|
• Heat transfer oil enters into the boiler from the top and drains out from the bottom is helpful for exhaust and not easy coked, thus makes the boiler long service life. • Simple structure, low cost, large heat absorption area, high thermal efficiency, environmental protection. |
| Model | YLL Type of Vertical Chain Grate Wood-fired Thermal oil Heater | ||||||||||
| Rated thermal power | KW | 350 | 500 | 700 | 1000 | 1200 | 1400 | 1900 | 2100 | 2400 | 3000 |
| ×104 kcal/h | 30 | 40 | 60 | 80 | 100 | 120 | 160 | 180 | 200 | 250 | |
| Designed thermal efficiency(%) | ≥75 | ||||||||||
| Rated working pressure (Mpa) | 1 | ||||||||||
| Max.operating temperature (°C) | 350 | ||||||||||
| Thermal oil capacity (m³) | 0.36 | 0.54 | 0.61 | 0.78 | 0.97 | 1.12 | 1.87 | 1.98 | 2.34 | 3.02 | |
| Circulating oil Capacity (m3/h) | 30 | 40 | 60 | 80-100 | 90-120 | 100-120 | 160 | 160 | 180 | 200 | |
| The main thermal coal caliber (mm) | 80 | 100 | 100 | 125 | 125 | 125 | 150 | 150 | 150 | 200 | |
| System-wide installed capacity (KW) | 15 | 21 | 25 | 30 | 40 | 52 | 62 | 70 | 70 | 85 | |
| Design fuel | Rich husk | ||||||||||
| Fuel Consumption (kg/h) | 86 | 114 | 172 | 230 | 287 | 344 | 458 | 516 | 573 | 717 | |
