Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > 8Kw Yanmar Diesel Generator Prices
8Kw Yanmar Diesel Generator Prices
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Boomaster
Model Number:
BM11YM5
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
56kva Yanmar Diesel Generator SetUS$ 1,999 - 19,999MOQ: 1 Set -
49kva China Yanmar Diesel Generator Power Plant DesignUS$ 3,900 - 4,600MOQ: 1 Set
-
41kva China Yanmar Diesel Generators PrecoUS$ 2,450 - 3,000MOQ: 1 Set
-
20kva Yanmar Diesel Generator Buy Stirling Engine GeneratorUS$ 1,900 - 2,400MOQ: 1 Set
-
33kva China Yanmar Diesel Generators Stirling Engine GeneratorUS$ 2,240 - 2,700MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
Boomaster
Model Number
BM11YM5
Output Type
AC Three Phase
Speed
1500Rpm
Frequency
50Hz
Rated Power
8Kw/10Kva
Rated Voltage
120/208V,230/400V
Specifications
8Kw Yanmar Diesel generator prices1.Quality Approvals
2.Small Orders Accepted
3.Enjoy Good Reputation
|
8Kw Yanmar Diesel generator prices
|
|
| 1) Brand-new engine,w/start motor. | |
| 2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR. | |
| 3) Auto control panel with LCD display. | |
| 4) Engine mounted battery-charging alternator,Genset with battery charge of main supply. | |
| 5) Circuit Breaker,Exhaust Silencer. | |
| 6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard. | |
| 7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable. | |
| 8) Skid-mounted bottom 8 hours fuel tank. | |
| 9) Extemal recessed emergency stop button for extra safety. | |
| 10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system. | |
| Genset Specification | |
| Genset Model | BM11YM5(50Hz) |
| Prime Power(Kva/Kw) | 8Kw/10Kva(50Hz) |
| Engine Model | YANMAR 3TNV82A |
| Alternator Model | PI044E(50Hz) |
| Speed Control type | Centrifugal-all speed governor |
| Phase | Three |
| Fuel Tank Capacity | 50 L |
| System Voltage | 12V |
| Frequency | 50/60 Hz |
| Fuel injection pump | Bosch in-line, Yanmar made |
| Emission level | Stage 4 |
| Dimension(L*W*H mm) | |
| Open Type | 1460*730*1170 |
| Silent Type | 1800*740*1150 |
| Engine Detail | |
| Model | YANMAR 3TNV82A |
| Maximum output(kw) | 11KW(50Hz) |
| Number of Cylinders | 3 |
| Aspiration | Naturally aspirated |
| Cycle | 4 |
| Fuel Type | Diesel |
| Combustion Type | Indirect Injection |
| Cooling Type | Water cooled |
| Coolant Capacity | 1.8 liter |
| Lubrication Capacity | 5.5 liter |
| Bore*Stroke | 82*86mm |
| Displacement | 1.331 L |
| Compression ratio | 19.2:1 |
| Alternator Detail | |
| Model | PI044E(50Hz) |
| Insulation | Clase"H" |
| Execitation Type | Self-excitation |
| Protection class | IP23 |
