Yanma Engine Silent Type Diesel Generator

Specifications

yanma engine sielnt type diesel generator
1.CE,ISO
2.Deepsea controller,ATS
3.1000 hours/12 months warranty
4.Low noise

yanma engine silent type diesel generator

Generator Supply Scope:

Ø .Standrad tool kits and complete operation/maintenance/spare parts manuals to Engine/Alternator
Ø .brand-new engine, w/ start motor.
Ø .brand new brushless alternator, single bearing, flange connection, IP23, H insulation class, with AVR.
Ø .auto control panel, with LCD display.
Ø .Engine mounted battery-charging alternator, Genset with battery charger of mains supply.
Ø .Circuit Breaker,Exhaust Silencer
Ø .Copper Radiator for 50°C ambient temperature and bouble-deck cooling,with fan guard and front guard
Ø .Antivibration pads are fixed between engine/alternator and base frame,as to ensure the compete genset running under stablilization.
Ø .Skid-mounted bottom Fuel tank - 8hrs continous running(bigger fuel tank by your demand under extra cost)
Ø .External recessed emergency stop button for extra safety
Ø .The colors & Brands by your requests
Ø .Optional Choice:Soundproof, ATS (automatic transfer switch), AMF panel, Trailer, Parallel system by your extra choose

Diesel Engine Specifications

Engine Model	2TNV70-HE
Engine manufacturer	Yanmar
Number of Cylinders	2
Cylinder arrangement	Vertical in line
Cycle	4-cycle
Intake system	Turbocharged
Bore x Stroke (mm x mm)	70 x 74
Displacement (L)	0.57
	19.
Prime Power/Speed (KW / rpm)	6 / 1500
Standby Power/Speed (KW / rpm)	7.5 / 1500
Speed Governor	Mechanical
Cooling System	Water-cooled, 40°C Radiator as Standard, 50°C Is Optional
Speed Stability (%)	≤5%
Lubrication system capacity (L)	6.7
Coolant capacity (L)	2
Fuel Consumption at 100% Load (g/kWh)	245 (at 1500RPM)
Starter Motor	DC12V
Alternator	AC12V



Alternator Specifications

Brand	Original Stamford
Model	PI 044D
Prime Power	6KW / 7.5KVA
Rated Current (A)	11
Rated Voltage	220V / 380V
Frequency	50HZ @ 1500rpm
Power Factor(COS)	0.8
Phase	3-phase 4-wire
Excitation	Brushless, Self-excited, Automatic voltage regulation. Insulation Class: H .  Protection Grade : IP23.
Voltage Regulation	AVR
The regulating rate of steady voltage	≤1%
The regulating rate of instantaneous voltage:	-15%~ +20%
The time of steady voltage:	≤1.5sec
The waving rate of voltage:	≤1.0%
The regulating rate of steady frequency:	≤3%
The regulating rate of instantaneous frequency:	≤±10%
The time of steady frequency:	3sec
The waving rate of frequency:	≤1%



Generator set warranty and maintenance:



Ø Do the full power load test for five hours before package.

Ø One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.

Ø After expiration, we provide spare parts maintenance with low price.



Other pictures:





 Silent diesel generator
