Diesel Penjana

Diesel Penjana thumbnail-1
Diesel Penjana photo-1
US$ 2,999 - 99,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Deutz
Model Number:
BD series
Contact Supplier Request Quote Chat Now
Elephant Tech Fuzhou Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ANY PORT IN CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Deutz
Model Number BD series
Output Type AC Three Phase
Speed 1500/1800rpm
Frequency 50/60Hz
Rated Power 10-500Kw
Rated Voltage 120/208V,230/400V
Rated Current 9-999A

Specifications

diesel penjana
1.Deutz engine
2.Stamford alternator
3.Smartgen controller
4.Stable Power/Low Fuel Consumption

diesel penjana


Technical Data

230/400  50/60HZ  Power factor:0.8   three phase 4 wires



Product Overview

1) Brand-Deutz

2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR.

3) Auto control panel with LCD display.

4) Engine mounted battery-charging alternator,Genset with battery charge of main supply.

5) Circuit Breaker,Exhaust Silencer.

6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard.

7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable.

8) Skid-mounted bottom 8 hours fuel tank.

9) Extemal recessed emergency stop button for extra safety.

10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system.



Power by Deutz (air-Cooled) Engine
Model 50Hz,400/230V,COS=0.8, Parameters of Deutz Fuel Consumption Dimension & Weight
3 Phase 4 Wire diesel engine 1500rpm Genset Dimension Weight
Genset Output(Kw/kva) Engine Cylinder (full load)l/hr
Prime Power Standby Power Model Number L * W * H (mm) (Kg)
BD-12.5 10/12.5 11/13.8 F2L912 2 4.3 1400*900*1100 580
BD-30 24/30 26.4/33 F3L912 3 7 1500*1000*1150 635
BD-38 30/38 33/41.3 F4L912 4 9.5 1550*1050*1150 790
BD-42.5 34/42.5 37.4/46.8 F4L913 4 12 1600*1050*1150 800
BD-50 40/50 44/55 F6L912 6 13.2 1650*1000*1200 820
BD-60 50/60 55/68.8 F6L913 6 15 2070*1150*1250 900
BD-75 60/75 66/82.5 F6L913T 6 16.8 2070*1200*1250 970
BD-87.5 70/87.5 77/96.3 BF6L913 6 17.9 2150*1250*1300 1020
Power by Deutz (Water-Cooled) Engine
Model 50Hz,400/230V,COS=0.8, Parameters of Deutz Fuel Consumption Dimension & Weight
3 Phase 4 Wire diesel engine 1500rpm Genset Dimension Weight
Genset Output(Kw/kva) Engine Cylinder (full load)l/hr
Prime Power Standby Power Model Number L * W * H (mm) (Kg)
BD-30 24/30 26.4/33 D226B-3D 3 7 1800*850*1150 635
BD-37.5 30/37.5 33/41.2 TD226B-3D 3 9.5 1900*850*1260 790
BD-62.5 50/62.5 55/68.7 TD226B-3D 4 13.2 2150*950*1350 850
BD-93.7 75/93.7 82.5/103 TD226b-6D 6 15 2450*1050*1450 1150
BD-125 100/75 110/137.5 TBD226B-6D 6 16.8 2570*1100*1550 1200
BD-137.5 110/137.5 121/151 TBD226B-6D5 6 17.9 2650*1200*1600 1500



Generator soundproof/Silent and canopy box:

Ø         8 hours’ base fuel tank

Ø         Excellent ventilation

Ø         Black finish stainless steel locks and hinges

Ø         Zinc plated or stainless steel fasteners

Ø         Body made from steel components treated with polyester powder coating

Ø         Two large doors on either side

Ø         Radiator fill access plate

Ø         Fully guarded cooling fan and battery charging alternator

Ø         Fuel fill and battery access via lockable access doors

Ø         Emergency stop button on canopy exterior

Ø         Lube oil drain and radiator drain to exterior

Ø         Control panel viewing window

Ø         Lifting points on base frame

Ø         1m<80DBA / 7m<70DBA



Generator set warranty and maintenance:

Ø         Do the full power load test for five hours before package.

Ø         One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.

Ø         After expiration, we provide spare parts maintenance with low price



Air cooled Deutz Open Diesel Generator



diesel penjana



Water cooled cooled Deutz Open Diesel Generator



diesel penjana



diesel penjana



Silent/Sundproof Diesel Generator



diesel penjana



diesel penjana
