20kva Silent Deutz Engine Generator
US$ 1,000 - 25,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Deutz
Model Number:
Deutz series
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
24kw/30kva Deutz Engine Parts Diesel GeneratorUS$ 1,000 - 25,000MOQ: 1 Set -
Alternator for Generator With Open or Silent Type and CE CertificateUS$ 4,500 - 5,000MOQ: 1 Set
-
20kva Silent Water-cooled Deutz Generator With High PerformanceUS$ 5,600 - 6,000MOQ: 1 Set
-
Deutz Engine Air Cooled Electric GeneratorUS$ 999 - 9,999MOQ: 1 Set
-
14kw 3 Phase Silent Encolsed Air Cooled GeneratorUS$ 999 - 9,999MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
Deutz
Model Number
Deutz series
Output Type
AC Three Phase
Speed
1500/1800
Frequency
50/60Hz
Rated Power
500kva
Rated Voltage
20kva
Rated Current
10-100A
Specifications
20kva silent deutz engine generator1.Deutz diesel engine
2.50/60Hz
3.CE/EPA/ISO9001
20kva silent deutz engine generator
- Technicial data
| DEUTZ Series 30-160KVA POWER DIESEL GENERATOR | |||||||
| genset | genset model | D-30 | D-45 | D-60 | D-100 | D-140 | D-160 |
| Prime output(kw/kva) | 24/30 | 36/45 | 48/60 | 80/100 | 112/140 | 128/160 | |
| Stand output(kw/kva) | 26/33 | 40/49 | 53/66 | 88/110 | 123/154 | 140/176 | |
| engine | Engine Type: | D226B-3D | TD226B-3D | TD226B-4D | TD226B-6D | TBD226B-6D | TBD226B-6D5 |
| Engine brand | Deutz | Deutz | Deutz | Deutz | Deutz | Deutz | |
| 12h Rate output(kw) | 30 | 45 | 60 | 90 | 120 | 132 | |
| Cylinder numbers(L) | 3 | 4 | 4 | 6 | 6 | 6 | |
| Type: | STG184G | STG224C | STG224E | STG274C | STG274E | STG274F | |
| Brushless Alternator | Prime output(kw/kva) | 23/31.3 | 34/42.5 | 48/60 | 80/100 | 112/140 | 128/160 |
| Characteristic | Stamford Model .Brushless Self excitation. With AVR | ||||||
| Rated voltage: | 230/400V | ||||||
| Rated frequency: | 50Hz | ||||||
| Power factor | 0.8 lagging | ||||||
| phase/connection | 3-phase,4-wire | ||||||
| Diesel Genset | Standar parts: | storage batter. 8hours the fuel tank.Emergency stop switch.shock absorbers. radiator.silencer,drain outlet ,fuel systerm etc | |||||
| Additional Part: | Digital Control Panel and Genset protection | ||||||
| Noise (db) | silent genset 55-78 dba @ 7m , open type75-98 dba @7m | ||||||
| Open type | Dimenstion(mm) | 1600*700*1450 | 1700*700*1450 | 2000*700*1450 | 2400*700*1450 | 2400*700*1450 | 2400*700*1450 |
| Weight(Kg) | 600 | 700 | 800 | 1200 | 1300 | 1400 | |
| Soundproof Type | Dimenstion(mm) | 1800*900*1550 | 1900*900*1550 | 2200*900*1550 | 2700*900*1550 | 2700*900*1550 | 2700*900*1550 |
| Weight(Kg) | 750 | 850 | 1000 | 1400 | 1500 | 1600 | |
- optional parts:
- Related product:
- Our factory:
- Exhibition:
- Packaging:
- Certificate:
