6CTA8.3-G2 Power by 175kva Slient Water-cooled Cummins Engine Diesel Generator Price List
US$ 19,999 - 29,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
cummins power
Model Number:
BC-175
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
4BT3.9-G2 38kva Cummins Engine Slient Diesel Generator in StockUS$ 5,999 - 6,999MOQ: 1 Set -
6BT5.9-G2 Power by 90kw Cummins Engine Genset for SaleUS$ 1,000 - 9,999MOQ: 1 Set
-
KTA38-G5 800kw Cummins Engine Genset for SaleUS$ 1,000 - 9,999MOQ: 1 Set
-
KTA38-G2A Power by 32-1800KW Cummins Engine Generator With Stamford AlternatorUS$ 4,500 - 250,000MOQ: 1 Set
-
40kw Cummins Engine Soundproof Electric Generator for Sale Quality ChoiceUS$ 4,500 - 250,000MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
cummins power
Model Number
BC-175
Output Type
AC Three Phase
Speed
1500/1800Rpm
Frequency
50Hz
Rated Power
140kw
Rated Voltage
220/380V 230/400V
Rated Current
266A
6CTA8.3-G2 power by 175kva slient water-cooled cummins engine diesel generator
price list
| Product Overview | |
| 1) Brand-Cummins power | |
| 2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR. | |
| 3) Auto control panel with LCD display. | |
| 4) Engine mounted battery-charging alternator,Genset with battery charge of main supply. | |
| 5) Circuit Breaker,Exhaust Silencer. | |
| 6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard. | |
| 7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable. | |
| 8) Skid-mounted bottom 8 hours fuel tank. | |
| 9) Extemal recessed emergency stop button for extra safety. | |
| 10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system. | |
| 6CTA8.3-G2 power by 175kva Cummins diesel generator | |
| Genset Specification | |
| Genset Model | BC-175 |
| Prime Power(Kw/Kva) | 140/175 |
| Frequency | 50Hz |
| Structure type | Open or Soudproof |
| Dba"@7m | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
| Engine Model | 6CTA8.3-G2 |
| Alternator Model | STG274G |
| Open type DimensionL*W*H(mm) | 2200*850*1500 |
| Weight(Kg) | 1900 |
| Silent type DimensionL*W*H(mm) | 2400*1100*1700 |
| Weight(Kg) | 2200 |
| Engine Detail | |
| Manufacturer | Chongqing cummins engine Co.,Ltd |
| Model | 6CTA8.3-G2 |
| Engine speed | 1500rpm |
| Engine Characters | water-cooled,6cylinders in line,4-cycle,direct injection |
| The maximum output(kw) | 190KW |
| Aspiration | Turbocharged |
| Bore(mm)xStroke(mm) | 114*135 |
| Compression ration | 16.5:1 |
| Fuel consumption(L/H) | 40(100%loading) |
| Displacement(Liters) | 8.3 |
| Exhaust air flow(m3/min) | 176 |
| Compress air flow(m3/min) | 7.6 |
| Exhaust gas flow(m3/min) | 21 |
| Exhaust highest temperature | 638°C |
| Lube-oil pan capacity(L) | 16.4 |
| Cooling water capacity(L) | 12.3Liters(Engine only) |
| Voltage for start(V) | 24 |
| Instrument for adjusting speed | Electronically |
| Noise level(A)@7m | <96dBA(open type) ,<72dBA(silent type) |
| Alternator Detail | |
| Model | STG274G |
| Output power(Kw/Kva) | 140/175 |
| Number of phase | 3 |
| Power factor(Cos Phi) | 0.8 |
| Number of Pole | 6 |
| Exciter type | Shunt |
| Insulation class | H |
| Voltage regulation | 0.50% |
| Total haarmonics (TGH/THC) | 4% |
| Wave form:Nema=TIF | 50 |
| Wave form:I.E.C=THF | 2% |
| Bearing | single |
| Coupling | Direct |
Generator soundproof/Silent and canopy
Ø Excellent ventilation
Ø Black finish stainless steel locks and hinges
Ø Zinc plated or stainless steel fasteners
Ø Body made from steel components treated with polyester powder coating
Ø Two large doors on either side
Ø Radiator fill access plate
Ø Fully guarded cooling fan and battery charging alternator
Ø Fuel fill and battery access via lockable access doors
Ø Emergency stop button on canopy exterior
Ø Lube oil drain and radiator drain to exterior
Ø Control panel viewing window
Ø Lifting points on base frame
Ø 1m<80DBA / 7m<70DBA
Generator set warranty and maintenance:
Ø Do the full power load test for five hours before package.
Ø One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.
Ø After expiration, we provide spare parts maintenance with low price
Cummins power :
Factory photo
Exhibition
Certificate
