800KW Jichai Name Generator
Specifications
1.800KW Jichai name generator2.Many Engines available
3.Three phase,50/60HZ
4.Low noise/stable power
5.Manufacturer
800KW Jichai name generator
Genset main technical data
3-PH, 50Hz @ 1500RPM, 400/230V, P.F. =0.8
Genset Model |
Genset Specification |
Engine Specificaiton |
Alternator |
|||||||
Prime Power |
Standby Power |
Cons.100% (g/kW.h) |
Model |
Cyl. |
Gov. |
Asp. |
Model |
|||
kVA |
kW |
kVA |
kW |
|||||||
BMJ1000 |
1000 |
800 |
1100 |
880 |
205 |
Z12V190B |
12 |
M |
TCAA |
TPA404S4 |
|
Dimension (L×W×H) mm |
Weight kg |
Open Type |
5925×2040×2678 |
13700 |
Silent Type |
- |
- |
Engine Model |
Z12V190B |
Type |
4 cycle, water-cooled diesel |
Number of cylinders |
12 |
Bore×stroke |
190 mm×210 mm |
Combustion system |
Direct injection |
Compression ratio |
14:1 |
Displacement |
71.45 L |
Rated output |
882 kW |
1500 min-1 | |
Continuous rating |
794 kW |
1500 min-1 | |
Specific fuel consumption |
≤209.4 g/kW.h |
Oil consumption |
≤1.6g/kW.h |
Aspiration |
Turbocharged and aftercooled |
Oil capacity |
200L |
Starter |
Electrical |
Direction of rotation |
Counterclockwise (Viewed from F.W.) |
Manufacturer |
BOOMASTER Power System Co., Ltd. |
Model |
TPA404S4 |
Rated power |
800KW |
AVR type |
MX341 |
Phase and connection |
3 Phase 4 Wire |
Power factor(Cos Phi) |
0.8 |
Altitude |
≤1000m |
Overspeed |
2250min-1 |
Excitation system |
PMG |
Insulation class |
H |
Degree of protection |
IP23 |
Voltage regulation |
±1% |
Winding pitch |
2/3 |
Number of wires |
6 |
Harmonic distortion TGH/THC |
no load <3% - on load <2% |
Waveform: NEMA=TIF |
≤50 |
Waveform: IEC=FHT |
≤2% |
