UK Lister Petter Diesel Generator for Sale
Technical Data
230/400 50/60HZ Power factor:0.8 three phase 4 wires
Product Overview
1) Brand- UK Lister Petter
2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR.
3) Auto control panel with LCD display.
4) Engine mounted battery-charging alternator,Genset with battery charge of main supply.
5) Circuit Breaker,Exhaust Silencer.
6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard.
7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable.
8) Skid-mounted bottom 8 hours fuel tank.
9) Extemal recessed emergency stop button for extra safety.
10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system.
| 50 Hz, 1500 r/min | 60 Hz, 1800 r/min | |||||
| Model | Engine | Rating | kVA | kWe | kVA | kWe |
| DG 33LP | GW3 | Prime | 30 | 24 | 31 | 25 |
| Standby | 33 | 26 | 34 | 27 | ||
| DG50LP | GW4 | Prime | 45 | 36 | 48 | 38 |
| Standby | 50 | 40 | 53 | 42 | ||
| DG70LP | GWT4 | Prime | 63 | 50 | 69 | 55 |
| Standby | 69 | 55 | 75 | 60 | ||
| DG100LP | GWT6-1A | Prime | 90 | 72 | 94 | 75 |
| Standby | 100 | 80 | 106 | 85 | ||
| DG110LP | GWT6-2A | Prime | 100 | 80 | 113 | 90 |
| Standby | 110 | 88 | 125 | 100 | ||
| DG138LP | GWTA6 | Prime | 125 | 100 | 138 | 110 |
| Standby | 138 | 110 | 150 | 120 | ||
| Approximate fuel consumption | |||
| Litres/hour at 100% load | |||
| Model | Engine | 50 Hz, | 60 Hz, |
| 1500 r/min | 1800 r/min | ||
| DG 33LP | GW3 | 7 | 7.5 |
| DG50LP | GW4 | 10.8 | 11.5 |
| DG70LP | GWT4 | 14.7 | 15.9 |
| DG100LP | GWT6-1A | 20.5 | 22 |
| DG110LP | GWT6-2A | 22.6 | 26 |
| DG138LP | GWTA6 | 27.7 | 30.9 |
| Average sound pressure level * | |||
| Acoustic housing | 75% load at 7m | ||
| DG70LP (50HZ) | 73.5 dBA | ||
| Rating Definitions to ISO 8528-1 | |||
|
All ratings are in accordance with ISO 8528-1. Power outputs are based on the optimum make of alternator for the set. Gensets fitted with other manufacturers’ alternators may not achieve the above ratings | |||
| Rating Conditions | |||
|
A standard generating set is designed to operate in environmental reference conditions of 25 °C, 100 kPa and 30% humidity. | |||
| Prime Power | |||
|
This rating is for the supply of continuous electrical power (at variable load). There is no limit on the annual hours of operation and 10% overload power can be supplied for 1 hour in 12. | |||
| Standby Power | |||
|
This rating is for the supply of continuous electrical power (at variable load) in the event of a utility power failure. No overload is permitted. | |||
Generator soundproof/Silent and canopy box:
Ø 8 hours’ base fuel tank
Ø Excellent ventilation
Ø Black finish stainless steel locks and hinges
Ø Zinc plated or stainless steel fasteners
Ø Body made from steel components treated with polyester powder coating
Ø Two large doors on either side
Ø Radiator fill access plate
Ø Fully guarded cooling fan and battery charging alternator
Ø Fuel fill and battery access via lockable access doors
Ø Emergency stop button on canopy exterior
Ø Lube oil drain and radiator drain to exterior
Ø Control panel viewing window
Ø Lifting points on base frame
Ø 1m<80DBA / 7m<70DBA
Generator optional:
Engine |
Heater |
Battery Charger |
|
Fuel System |
Daily Fuel Tank |
Base Fuel Tank |
|
Control System |
Auto Control Panel |
Remote Control Panel |
Auto Transfer Switch (ATS) Control Panel |
Alternator |
Single phase, three phase |
Brushless, carbon brush |
|
Type |
Weatherproof Type |
Soundproof Type |
Trailer type |
Spare Parts |
Fuel filer, Oil filter, air filter, tank pad, Triangle Belt, tools and Engine Parts Drawing List |
||
Generator set warranty and maintenance:
Ø Do the full power load test for five hours before package.
Ø One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.
Ø After expiration, we provide spare parts maintenance with low price
UK Lister Petter Diesel Generator
Our Factory Generator Workshop
Production equipment of generator
Exhibition of Generator
Certification of Generator
