Specifications
electrical steam boiler1. Class A boiler
2. Fuel:Electricity
3. Power:0.05t-5.0t
4. Usage:Hotel, School, Bath,laudry
Industrial electrical steam boiler for laundry equipment
A. The unique features of electric steam boiler
1.PLC control, automatically operating, no worker, easy operating.
2.With fantastic burn, auto lightening, burning, flame protection, and automatic blowing.
3.Inner special treatment, hot water safety, and clean.
4. Hotel, school, bathing house, warming etc.
B. Why are you choose electric steam boiler ?
(1).Factory assurance:
One year parts warranty
Spare parts available at ex-factory price
Different voltage available
100% tested before delivery
WNS steam boiler capacity ranging from 500 -- 30000 Kg/h.
Skid-mounted complete system available 100-- 2000 kg/h.
Complete system fixed in container available 100-- 4000 kg/h.
Engineer on-site instruction of installation and commissioning available.
(2).After-sale services:
1. Assist clients to prepare for the first construction, and also can arrange engineer on-site instruction of installation and commissioning
2. Install and debug the equipment;
3. Train the first-line operators;
(3). Company Introduction:
Spirit: Supply Reliable & high efficient heating system.
1, More than 600 sets of boilers (5000 t/h) can be produced by us per year. Class A boiler manufacturer. Class A1, A2 pressure vessel manufacturer.
2, Each boiler system parts is from first class brand all over the world or China.
3, Strict quality control system. From the material, welding, to finished boiler shipment. From project establishment, drawing design, to final audit.
4, We are the stable and long term supplier of many Top 500 Groups all over the world. Such as PetroChina, Sinopec, Nestle, Mercedes-Benz, Coca cola, etc,.
C. Electric steam boiler parameter
| Itemmodel | LDR0.05--0.4-D | LDR0.1--0.4/0.7-D | LDR0.2--0.4-D | LDR0.2--0.7-D | LDR0.3--0.4/0.7-D | WDR0.5--0.7-D | WDR1.0--0.7/1.0-D | WDR1.5-1.0-D | WDR2.0-1.0-D | |
| rated heat capacity kw | 36 | 75 | 144 | 144 | 216 | 360 | 720 | 1080 | 1440 | |
| rated steam capacity | 0.05 | 0.1 | 0.2 | 0.2 | 0.3 | 0.5 | 1 | 1.5 | 2 | |
| rated working pressure MPa | 0.4 | 0.4/0.7 | 0.4 | 0.7 | 0.4/0.7 | 0.7 | 0.7/1.0 | 1.0 | 1.0 | |
| Power x class number Kw x n | 12x3 | 15x5 | 24x6 | 24x6 | 24x9 | 24x15 | 24x30 | 33x32 | 24x60 | |
| saturated steam temperature °C | 154 | 154/170 | 154 | 170 | 154/170 | 170 | 184 | 184 | 184 | |
| Designed thermal efficiency(%) | ≥98 | |||||||||
| rated operational voltage V | ~ 380 V | |||||||||
| mode of connection | three-phase three-wire system | |||||||||
| Steam caliber DN | 20 | 25 | 40 | 40 | 40 | 50 | 65 | 65 | 80 | |
| Inlet Diameter DN | 20 | 25 | 25 | 25 | 25 | 25 | 40 | 40 | 40 | |
| safe vavle diameter DN | 25 | 40 | 40 | 40 | 40 | 40 | 2x40 | 2x40 | 4x40 | |
| blowdown valve diameter DN | 25 | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 | |
| Boiler Weight Kg | 160 | 220 | 420 | 486 | 500/ 550 | 1980 | 2245 /2300 | 2600 | 4000 | |
| outlook size | length m | 700 | 890 | 1180 | 1120 | 1220 | 2450 | 2450 | 2800 | 2500 |
| width m | 470 | 700 | 960 | 970 | 980 | 1700 | 1800 | 2000 | 2000 | |
| height m | 1250 | 1310 | 1470 | 1520 | 1520 | 1700 | 2000 | 2050 | 2300 | |
| Notes:This form only for your reference,if any changed,please refer to Ex-factory technical documents. | ||||||||||
D.Other boilers
E.Pictures of manufacturer show
F.Picture of exhibition show
G: Let us be business partner
