5kw slient diesel generator

Name: 5kw slient diesel generator
Brand: Boomaster
Availability: InStock

FOB Price

USD $999 - $9,999 / Set

1 Set(Min.Order)

Supply Ability 300 Set / Sets per Month
Port any chinese port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China	Brand Name	Boomaster
Model Number	BG10-200kva	Output Type	AC Three Phase
Speed	1500rpm	Frequency	50hz
Rated Power	5kw	Rated Voltage	230/400v,.120/208v

Product Description

Specifications

5kw slient diesel generator
1.Model:DG5500
2.output power:5kw
3.Voltage:220/380V,230/400V
4.Frequency:50Hz

5kw slient diesel generator

1.Model:DG5500
2.output power:5kw
3.Voltage:220/380V,230/400V
4.Frequency:50Hz

some features are as following:

Advanced AVR offers over-voltage, overheated and overload protection for the generator.
Frame designed for better protection.
3-phase generator available for construction use.
Hydraulic-Magnetic circuit breaker for overload protection and convenience.
10HP max output diesel engine.
11.5L fuel tank ensures 6.5 hours of continuous running.

Specifications:

AC Frequency (Hz)		50Hz
AC Output voltage(V)		220/380;230/400
Rated AC Output		5kW
Max.AC Output		5.5kW
Power Factor		0.8
DC Output		12V/6.7A
Engine		DG186
Type		Single-Cylinder,4-Stroke,Air-Cooled Diesel Engine
Displacement(cc)		418
Starting System		Electric Starter
Lubrication oil		SAE 10W/30
Max.Output(hp/rpm)		10/3000
Fuel Tank Capacity(l)		11.5
Continuous Work(h)		6.5
Noise Level LwA dB(A)		96
Dim(mm)		727X495X597
Gross Weight(kg)		98
20ft Container Qty		102
40ft Container Qty		216

Other information:

ü Power for emergency and home standby use

ü Overload protection for safe running

ü Compact structure and light weight

ü Easy maintenance with brushless alternator electric ignition

ü Large fuel tank for a long time of continuous running

ü Emergency low oil warning

Features and benefits

a) Powered by BOOMASTER 4-Stroke

b) Large muffler for quiet operation.

c) Standard configuration of voltmeter.

d) Neat and economical for classical design.

e) Circuit breaker protects overload operation.

f) Emergency low oil alert warn the low lube oil level.

g) AVR alternator provides stable voltage and current.

Optional Parts

1. Electric start and Storage battery

2. wheel and Handles
