CCS Marine Generator
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Cummins
Model Number:
BM-85
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Diesel Marine EngineUS$ 5,000 - 10,000MOQ: 1 Set -
Deutz Marine GeneratorUS$ 5,000 - 10,000MOQ: 1 Set
-
Yanmar Marine Generator With CCS CertificateUS$ 5,000 - 10,000MOQ: 1 Set
-
Inboard Diesel Marine Generators With Sea Water Cooling for BoatsUS$ 10,000 - 12,000MOQ: 1 Set
-
50KVA Marine AC Diesel Generator SetUS$ 5,000 - 6,000MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
Cummins
Model Number
BM-85
Output Type
AC Three Phase
Speed
1500/1800rpm
Frequency
50/60Hz
Rated Power
85kva
Rated Voltage
230/400v,120/208v
Rated Current
223A
Specifications
marine generator1.rated power: 25-500kva
2.50/60hz'
3.opent type
4.long life time
CCS marine generator
1.Power range:25-250kva
2.Certificate:With CCS ceritificate
3.Engine:Cummins,Deutz ,Yanmar,and Chinese engine
4.Warranty:One year warranty
85kva 50hz CCS cummins marine generator
1)Data of Generator Set
| Technical Data | |||
| Marine Gensets Model | MG-85C | ||
| Rated capability (KVA) | 85 | ||
| Rated Power (KW) | 68 | ||
| Alternator Model | Marine Brushless Insulation Class H | TFW2-H-70 | |
| Diesel Model | 6BT5.9-GM183 | ||
| Rated output of engine(KW) | 85 | ||
| Cylinder No. | 6 | ||
| Bore*Stroke | 105*125 | ||
| Rated Voltage(V) | 120/240 | ||
| Phase/Connection | 3Ph×4W | ||
| Rated Frequency(Hz) | 50 | ||
| Power Factor(COSφ) | 0.8 | ||
| Rated speed (r/min) | 1800 | ||
| Fuel consumption (g/kw.h) | ≤210 | ||
| Starting type | Electric | ||
| Net Weight(kg) | 900 | ||
| Overall Dim. | L | 2200 | |
| (mm) | W | 900 | |
| H | 1450 | ||
Alternator Features:
1. Stamford, Leroy Somer, Marathon
2. Brushless, 4 poles, rotation magnet
3. IP21-23(NEMA1) enclose is standard for all industrial alternators
4. H class insulation system
5. AVR self-regulated, voltage regulation rate: ≤±1%
6. Simple installation and maintenance with easy access to terminals, rotating diodes and coupling bolts
7. Wide range of flange adaptors and single bearing disc coupling
8. Radio interference restraining accords with the stipulation of VDE0875-N and ISO8528
9. Moisture proof, sand-proof, dustproof, salt-proof and vibration-proof
Other pic:
Silent diesel generator
Our factory
Certification
