Specifications
Marine diesel generator 250KW1.Cummins engine,marine use
2.Marathon Alternator
3.Reasonable Price
4.1 year Warranty,3P4W
Marine diesel generator with CE ISO EPA SONCAP
Engine Model |
BMC310 |
Number of Cylinders |
6 cylinders in line |
Cycle |
4 stroke |
Aspiration |
Turbocharged and aftercooled |
Bore×Stroke |
140x 152 mm |
Displacement |
14.0L |
Compression ratio |
14.5:1 |
Prime Power/Speed |
284KW/1500rpm |
Speed Governor |
electrical |
Cooling System |
By radiator |
Fuel Consumption at 100% Load |
205 g/kw.h |
Starter Motor |
DC24V, |
Marathon Alternator (Standard)
Alternator Model |
MP-H-250-4 |
Prime power |
250KW |
Frequency/speed |
50HZ/1500rpm |
Exciter type |
Brushless, Self-excited |
Power factor |
0.8 |
Insulation Grade |
H |
Protection Grade |
IP23 |
Phase / wire |
3 phase 4 wires |
Output for your chosen.
| product | diesel engine model |
| 20kw cummins marine generator-50Hz | 4B3.9-G2 |
| 80kw cummins marine generator-50Hz | 6BT5.9-G2 |
| 145kw cummins marine generator-50Hz | 6CTA8.3-G2 |
| 200kw cummins marine generator-50Hz | 6LTAA8.9-G2 |
| 200kw cummins marine generator-50Hz | MTA11-G2A |
| 200kw cummins marine generator-50Hz | NT855-GA |
| 400kw cummins marine generator-50Hz | QSX15-G8 |
| 305kw cummins marine generator-50Hz | KTA19-G2 |
| 600kw cummins marine generator-50Hz | QSK23-G2 |
| 520kw cummins marine generator-50Hz | VTA28-G5 |
| 752kw cummins marine generator-50Hz | QST30-G3 |
| 512kw cummins marine generator-50Hz | KT38-G |
| 1180kw cummins marine generator-50Hz | KTA50-G5 |
Generator Supply Scope:
1. Brand New Cummins water cooled diesel engine
2. Brand New Stamford,Leroy somer, Marathon,AC atlernator, Ratings: 400/230V, 3Ph, 50Hz, 1500Rpm, 0.8PF, IP23, H insulation class
3. Radiator with engine driven fan mounted on skid.
4. Deepsea,Comap,Harsen,Smartgen Set mounted control panel
5. CHNT,DELIXI,MCCB mounted
6. Anti-vibration mountings as to ensure the compete genset running under stablilization.
7. 24V DC Electric start system and engine driven battery charger, lead-acid type starting batteries
8. Industrial silencers with flexible connects and elbow
9. Base fuel tank, with fuel gauge integrated in the base frame of generating set
10. Test report of generator, Set of drawings and O&M manuals
11.Optional Choice:Soundproof, ATS (automatic transfer switch), AMF panel, Trailer, Parallel system by your extra choose.Engine:
Guaranty:
Guarantee for one year or 1000 hours (whichever comes first) from ex-factory date. During the guarantee period, our Boomaster will provide the free easy-damaged spare parts for problems caused by our quality of production or raw materials,
except the damage caused by customer's incorrect manmade operation.
After expiration, our company will provides cost spare parts maintenance for genset
MOQ |
1 set |
Delivery Clause |
FOB Fuzhou |
Terms of payment |
T/T, L/C at sight |
.Leading Professional manufacturer of power generator
.Certification:CE EPA ISO IEC
.Fast delivery:we will do our best to meet your requirement when you need it.
.Product quality :Famous high quality engine.we offer spare parts.
.OEM is warmly welcomed
