High Precision Hydraulic Oil Cleaning Machine for Oil Depot

High precision hydraulic oil cleaning machine  for oil depot

Excellent Performance:

New polymer membrane filtration technology
Capacity 20 tons daily with continuous working pattern
Minimum precision can be  2 μm
Filter elements in various precison from 2~20 μm
Filter elements with acid and alkali resistance
Can be used as by-pass filter with 380V electric anti-explosion motor
Emulsified and Free water removal
Selectivity-pass characteristic of 3D pore structure polymer membrane material
3 tanks design in 4 levels filtration
High interception rate and low filtration cost
Lightweight appearance and small operating space
Filter elements can be used repeatedly after back-washed
Design service life is more than 20 years (except for filter elements)

Technical Parameters:
1.Model Type: JY-H330
2.Flow Rate: 30~40 L/min
3.Filtration System:
(1)Polymer Membrane Filter Elements (Can be used repeatedly after washing)
J22-401L------------------------------------------------------------10μm
J22-401H------------------------------------------------------------5μm
(2)Filter Element Quantity: 100 Pieces
(3)Function: Remove impurity particles, colloid and water
(4)Working Pressure: 0.2~0.35 Mpa
(5)Filtration Level: 4
(6)Service life: 2~3 Years or longer
4.Filtration Precision:
(1)Range: 2,5,10,15,25 μm
(2)Standard: 5~10 μm
5.Mouth:
Standard: DN20 or According to Requirements
6.Security:
With Pressure Safety Valve
7.Temperature:
Working Temperature: -10~70 ºC
8. Dimension: 1160*450*1000mm
9.Weight:148KG
10.Anti-hazard Classification: Grade 2
11.Power System:
(1)Electric Motor:380V
(2)Pump: Gear Pump
