High effective automatic oil water separator /oil treatment machinery
Excellent performance:
•New polymer membrane filtration technology
•Selectivity characteristics of polymer membrane is core technology.
•Oil-water separating is easy.
•High precision and deep filtration
•Guarantee the cleanness index of industrial oil
•Improve the efficiency of the engine
•Prolong engine service life
•The cost of filtration is low
| Technical Parameters | 1 | Model Number | JY-G200 |
| 2 | Working Pressure | 0.2~0.35Mpa | |
| 3 | Flow Rate | 32L/min,40L/min,63L/min | |
| 4 | Filtration Precision | 2,5,10,15,20,30μm | |
| 5 | Filtration Material | HDPE,PA | |
| 6 | Applicative Oil | Industrial Emulsified Oil | |
| 7 | Chemical Resistance | Widely Chemical Compatibility | |
| 8 | Power | 380V Motor | |
| 9 | Coalescence Filter Element | J150-500L | |
| 10 | Separation Filter Element | J150-500F | |
| 11 | Membrane Filter Element | J30-975H | |
| 12 | Service Life of Filter Element | 2~3 Year | |
| 13 | Warranty for Main Engine | 1 Year | |
| Functional Characteristics | 1 | Large flow diesel purification filter | |
| 2 | Polymer 3D mesh structure membrane filter element | ||
| 3 | High precision filtration | ||
| 4 | High interception rate | ||
| 5 | Oil-water separation | ||
| 6 | High dehydration efficiency | ||
| 7 | Combining precision filtration and high efficient dehydration | ||
| 8 | Continuous processing | ||
| 9 | Clean degree can reach NAS5 grade | ||
| 10 | Water rate in oil is less than 100ppm | ||
| 11 | Keeping the physical and chemical character of the oil | ||
| 12 | Extending oil service life | ||
| 13 | Low energy consumption, low operation cost | ||
| 14 | Simple and convenient operation and maintenance | ||
| 15 | Design life is more than 20 years (except for filter element) | ||
| Principle | Selectivity characteristic is to say, the oil molecules will pass and water molecules or impurities will be intercepted, so that the oil and water can be separated. | ||
| It adopts dehydration technology “coalescence separation”and coalescence separation filter targeted at oil special ratio on the basis of different medium surface tension to remove the emulsified water. | |||
| Application | Factories, mines, mechanical processing, engineering machinery,power plant and other industries in Asia, South America, Africa and Middle East. | ||
| Why do we filter diesel? | 90% of the failure problem of diesel engine is due to dirt and moisture in the diesel. After multiple storage and transportation, the purity of the product will decline. So filtering out the pollutants and water is necessary to restore the purity of the product. Clean diesel makes fuel consumption reduces 5-10%, oil-saving effect is obvious, the service life of diesel engines extend 2 ~3 times. | ||
Superiority:
Our machine used the newest membrane filter technology. the membrane element can wash and use again and again. so it can save much cost. membrane element has The characteristics of the oil drain. water and impurity can Successful intercept. and the clean oil pass . our precision can reach 2 micron. a hair is 80 micron, so you can think our precision , it is very high.
Function:
Special filter pump, extract the oil from the system tank,first cross a Magnetic filter and strainer,make the oil cross jingyuan
membrane filter element,The oil from the outer edge of the membrane filter into,Clean oil flow from the center of the membrane
filter hole,Impurities and moisture trapped on the outer edge of the membrane filter
Company information:
Shenyang Jingyuan Membrane Co.,Ltd. is a professional and innovative membrane filter manufacturer,specialized in clean diesel filter technologh,special membrane production technology,supplying with high performance and large flow of diesel purification filters and devices, industrial oil purification device, high proformance military filtration device. we are particularly skilled in research and application of membrane filtration materials, strict product quality control. we uphold the proprietary technology and creative and offer you qualified products,competitive price and professional services. we sincerely hope to promote and develop the business with our friends on the basis of equality and mutual benefit. Philosophy:Focus on research and development,continously innovate product,control quality in strict,base on equality and mutual benefit.
1>Durable Plywood Case packaging suitable for long distance ocean/train transportation.
2>Appointed shipping company could be used in shipment.
3>Whole process monitoring insures the safety of goods unitl arrival.
Our services---Term of Warranty:
1. One year with spare parts and service.
2. Engineers available to service machinery for overseas.
