Compelet Set Steam Coal Fired Water Tube Boiler
Class A SZL Series Coal Fired Chain Grate Hot Water Boiler
Dear Customer:
Welcome to our website and hope our products will make you satisfied .
We think creatively,design bravely,manufacture precisely and loyalty to
our customers. And we have our own We can produce the products
according to customer requirements .
Give us a negotiate chance will yield you a surprise .
Yours,
EPCB
Product Picture Show
Compelet Set Steam Coal Fired Water Tube Boiler
1.This series boiler belong to double drums water tube boilers, designed for blowdown on surface and the quality of steam is pretty good.
2.Steam boiler is devided into saturated steam boiler and overheat steam boiler and meet the needs in seperated.
3. Boiler main body and grate adopt large parts for ex-factory, short installation time and low charge for installation.
4. boiler capacity of 4-35T / H (2.8-29MW).
Product Data
SZL Series Coal-fired Hot Water Boiler Technique Parameter--- Compelet Set Steam Coal Fired Water Tube Boiler | |||||||
Item/Type |
SZL2.8-0.7/95/70-AII |
SZL4.2-1.0-115-70-AII |
SZL5.6-1.0-115/70-AII |
SZL7.0-1.0/115/70-AII |
SZL10.5-1.25/115/70-AII |
SZL14-1.25/130/70-AII |
|
Rated capacity MW |
2.8 |
4.2 |
5.6 |
7.0 |
10.5 |
14 |
|
Rated Working pressure Mpa |
0.7 |
1.0 |
1.0 |
1.0 |
1.25 |
1.25 |
|
Supply water Temperature Degree |
95 |
115 |
115 |
115 |
115 |
130 |
|
Return water temperature Degree |
70 |
70 |
70 |
70 |
70 |
70 |
|
Circulation Flow M3/h |
96 |
80 |
106 |
133 |
200 |
200 |
|
Heated area M2 |
Radiation convection |
15.6/112 |
21.6/132 |
25.2/171.5 |
29.5/204.1 |
37.21/284.68 |
58.4/307.4 |
Boiler Thermal efficiency % |
81 |
80.3 |
81.6 |
81 |
81 |
80 |
|
Fuel Consumption kg/h |
658 |
1002 |
1336 |
1688 |
2530 |
3375 |
|
Effictive area of grate M2 |
6.4 |
7.8 |
10.04 |
11.8 |
17.81 |
22.56 |
|
Max. transport size |
L (mm) |
7070 |
7860 |
6900 |
7900 |
9300 |
11500 |
W (mm) |
2750 |
2960 |
3100 |
3100 |
3300 |
3300 |
|
H (mm) |
3524 |
3524 |
3525 |
3525 |
3500 |
3540 |
|
Weight of largest parts of boiler transporting (T) |
31 |
33.5 |
29 |
39 |
43 |
54 |
|
Boiler is the energy conversion device. It is to convert the chemical energy of the fuel into heat energy, and then transfer heat to water, to produce hot water or steam.
Boiler is defined as a airtight device which can heat liquid in it to a certain parameter temperature through a variety of fuel, electricity or other energy sources and can carry a certain pressure.
Features of SZL boiler
1.This series boiler belong to double drums water tube boilers, designed for blowdown on surface and the quality of steam is pretty good.
2.Steam boiler is devided into saturated steam boiler and overheat steam boiler and meet the needs in seperated.
3. Boiler main body and grate adopt large parts for ex-factory, short installation time and low charge for installation.
4. boiler capacity of 4-35T / H (2.8-29MW).
After-sale Service of Us
1. 100%safety, running stably, excellent water level and pressure control, fully automatic operation.Coal Fired Chain Grate Hot water Boiler Coal Fired Chain Grate Hot water Boiler
2. Boiler running life > 20years. Chain Grate Hot water Boiler Chain Grate Hot water Boiler
3. Good after-sale service. It is free for you to get the damaged spares in warranty period (1 year) if there is any questions. Assure that we can supply you spares in boiler’s all life. SZL Series Coal Fired Chain Grate Hot water Boiler SZL Series Coal Fired Chain Grate Hot water Boiler
4. We can arrange engineer to your company for installation and commissioning and training. If you need us at any time, we can send our technicians and prepare in a short time.
5. Special paint is used after assembly. Paint is particularly used in your climate area, which is anti-corrosion, anti-abrasion and color-fastness.
Q: Are you manufacturer?
A: Yes, we are manufacturer. Our factory is in Pingdu Qingdao established in 1993.
Q: Do I get guarantee of products?
A: Yes, every product is 1 year quality warrantee under customer correct using the products.
Q: Do you have any Certificate?
A: Yes. Each of our boiler has China GB certificate. If you need CE ASME or AS, we can help you to get it.
Q: How to buy it?
A: Please contact me by email or online, let me know your factory situation, I will give you some advice which model mostly suitable to you.
Q: What about the delivery?
A: We have shipping agent can choosing the cheapest and fastest delivery. FOB,CIF, C&F or EXW are no problem for us
Q: How can I pay you?
A: T/T, LC is very well used.
Q: What about the production?
A: Produce time is 20~25days for <6Ton boiler, 25~40days for >8Ton boiler.
Q: Could you offer some wear parts?
A: Yes, some chain grate bars, electric equipments in control panel box for example.
Q: What about the maintenance?
A: I will offer you the timely maintenance way sheet after installation of the boiler mainly parts.
