Chinese offered biomass for small size Coal Chain Grate price
1. Including small and large flake type
2. Matching for 1-25t (samll),10-65t(large)
3. Flake type chain grate stoker(travelling grate),
Flake/squama type chain grate stoker (travelling grate) is a new style fire grate. It features compact, easy to install, not using longitudinal slag remover. During the period of installation, it is not necessary to install under guide rail and take civil engineering. What you need to do is to construct a concrete platform at site only. Not only it has the advantages of big squama type chain fire grate, such as good ventilation property, easy to maintain, etc but also it combines the features of light type chain belt fire grate, such as time saving and save labor when install.
It is whole quick assembling type fire grate with single layer arrangement. When purchase this kind of fire grate, customer needs small investment and low installation expense. Its performance of operation is constant and reliable. It is an ideal selection for small and middle boiler factory and use for boiler to match.
Flake type chain grate stoker has two types:
---Samll flake type chain fire grate: for 1t/h to 25t/h boiler
---Big flake type chain fire grate: 10t/h to 65t/h boiler
2. Advantages of our production and service
1),100%safety, running stably, excellent water level and pressure control, fully automatic operation
2), Boiler running life > 20years.
3), Good after-sale service. It is free for you to get the damaged spares in warranty period(1 year) if there is any questions. Assure that we can supply you spares in boiler’s all life.
4), We can arrange engineer to your company for installation and commissioning and training. If you need us at any time, we can send our technicians and prepare in a short time.
5), Special paint is used after assembly. Paint is particularly used in your climate area, which is anti-corrosion, anti-abrasion and color-fastness.
3. Paramiters:
| Applicable boiler | grate effective area(m2) | grate effective width(mm) | Grate surface height(mm) | Width between two endplates(mm) | Length of shaft out of grate(mm) | Height of shaft out of grate(mm) | Dia. of shaft out of grate(mm |
| 1t/h | 2.16 | 800 | 500 | 890 | 657 | 313 | Φ60 |
| 1t/h | 2.43 | 900 | 540 | 990 | 707 | 353 | Φ60 |
| 2t/h | 3.19 | 1100 | 540 | 1190 | 807 | 353 | Φ60 |
| 2t/h | 3.48 | 1200 | 540 | 1290 | 857 | 353 | Φ60 |
| 4t/h | 50.3 | 1300 | 540 | 1390 | 907 | 353 | Φ60 |
| 4t/h | 5.42 | 1400 | 540 | 1490 | 957 | 353 | Φ60 |
| 4t/h | 5.81 | 1500 | 590 | 1590 | 1007 | 403 | Φ60 |
| 6t/h | 6.63 | 1500 | 590 | 1590 | 1007 | 393 | Φ80 |
| 6t/h | 7.07 | 1600 | 590 | 1690 | 1057 | 393 | Φ80 |
| 6t/h | 7.51 | 1700 | 590 | 1790 | 1107 | 393 | Φ80 |
| 8t/h | 9.9 | 1800 | 690 | 1890 | 451 | Φ80 | |
| 10t/h | 12.6 | 2000 | 797 | 2090 | 555 | Φ80 | |
| 10t/h | 13.23 | 2100 | 797 | 2190 | 555 | Φ80 | |
| 15t/h | 18.82 | 2800 | 797 | 2890 | 555 | Φ100 | |
| 20t/h | 22.6 | 3400 | 797 | 3490 | 555 | Φ120/Φ110 | |
Ps: 1. suitable fuel : coal or biomass ; 2. used in boiler and furnace thermal technology equipment ; 3. The length and width can be change according to user needs. | |||||||
1. 100%safety, running stably, excellent water level and pressure control, fully automatic operation
2. Boiler running life > 20years.
3. Good after-sale service. It is free for you to get the damaged spares in warranty period(1 year) if there is any questions. Assure that we can supply you spares in boiler’s all life.
4. We can arrange engineer to your company for installation and commissioning and training. If you need us at any time, we can send our technicians and prepare in a short time.
5. Special paint is used after assembly. Paint is particularly used in your climate area, which is anti-corrosion, anti-abrasion and color-fastness.
Q: Are you manufacturer?
A: Yes, we are manufactuere. Our factory is in Pingdu Qingdao established in 1993.
Q: Do I get guarantee of products?
A: Yes, every product is 1 year quality warrantee under customer correct using the products.
Q: Do you have any Certificate?
A: Yes. Each of our boiler has China GB certificate. If you need CE ASME or AS, we can help you to get it.
Q: How to buy it?
A: Please contact me by email or online, let me know your factory situation, I will give you some advice which model mostly suitable to you.
Q: What about the delivery?
A: We have shipping agent can choosing the cheapest and fastest delivery. FOB,CIF, C&F or EXW are no problem for us
Q: How can I pay you?
A: T/T, LC is very well used.
Q: What about the production?
A: Produce time is 20~25days for <6Ton boiler, 25~40days for >8Ton boiler.
Q: Could you offer some wear parts?
A: Yes, some chain grate bars, electric equipments in control panel box for example.
Q: What about the maintenance?
A: I will offer you the timely maintenance way sheet after installation of the boiler mainly parts.
1. DZL new type water fire tube boilers (1-35T/H, 0.7-29MW)
2. SZL series water tube biomass boilers (4-35T/H, 1.4-29MW)
3. WNS series Horizontal oil/gas fired boilers (0.5-30T/H, 0.7-14MW)
4. LHS series Vertical Oil/gas fired boiler (0.1-2 T/H, 0.06-0.7MW )
5. SZS serires Horizontal Oil/gas fired boiler (4- 35T/H )
6. SHX boiler boiler ( 10--35 T/H)
7. CFB Circulating Fluidized Bed boiler ( 35T--130 T )
