Biomass Fired Boiler Wood Pellet Boiler Horizontal Type Using for Bangladesh

Name: Biomass Fired Boiler Wood Pellet Boiler Horizontal Type Using for Bangladesh
Brand: EPCB
Availability: InStock

FOB Price

US$ 10,000 - 300,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Natural Circulation
Usage	Industrial	Structure	Other, Water and fire tube industrial boiler
Pressure	Low Pressure	Style	Horizontal
Fuel	Other, coal, biomass, wood, oil, gas	Place of Origin	Shandong, China
Brand Name	EPCB	Model Number	DZL/SZL/WNS/YLW
Output	Other, steam, hot water, hot oil	Dimension(LWH)	Customization
Weight	5~50ton	Certification	ISO; GB; ASME; CE; PVOC; GOST
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Biomass steam boiler wood pellet boiler using for Bangladesh

Product Description

Dear Customer:

Welcome to our website and hope our products will make you satisfied .

We think creatively,design bravely,manufacture precisely and loyalty to

our customers. And we have our own factory. So we can produce the products

according to customer requirements .

Give us a negotiate chance and we will yield you a surprise .

Yours,

EPCB

Features Of DZG Fixed Grate Steam Boiler:

1.clean coke is a solid fuel, low sulfur dioxide emissions after combustion, in line with national environmental requirements.
2.use of mechanical ventilation, complete combustion, Powerful, high thermal efficiency.
3.cast carbon longer interval, low labor intensity, simple, safe and reliable.
4.capacity than the same fuel (gas) boiler-time low investment, low operation cost, is an economical and environmentally friendly boiler type.
5.application of fuel: coke, anthracite block, the installation of desulfurization equipment for coal for the same.
6.boiler capacity of 1-4T / H (0.7-2.8MW).

DZG series fixed grate boiler technique parameters
ItemType		DZG0.5-0.7/1.0-J	DZG1-0.7/1.0/1.25-J	DZG2-0.7/1.0/1.25-J	DZG0.35-0.7/95/70-J	DZG0.7-0.7/95/70-J	DZG1.4-0.7/95/70-J
Rated capacity t/h		0.5
Rated steam pressure Mpa		0.7/1.0
Rated steam temperature C		170/184
Feed water temperature C		20
Heated area M²	radiation /convection	2.3/16.2	4.68/16.1	5.8/30.7	2.3/16.2	4.55/20.12	6.17/39.5
Heated area M²	radiation /convection	2.3/16.2	4.68/16.1	5.8/30.7	2.3/16.2	4.55/20.12	6.17/39.5
Heat efficiency %		75	78	78	75	78	78
Fuel consumption kg/h		76	146	290	76	146	290
effective area of boiler M2		0.98	1.5	2.4	0.98	1.5	2.4
largest size of boiler transportation mm	length	2970	3782	4307	2970	3782	4900
	width	1950	1920	2130	1950	1800	2130
	height	2660	2820	3222	2660	2870	3222
weight of largest parts of boiler ton		8.3/8.4	11/11/11.6	15.7/15.8/16	8.3	11	15.5
