120w Foldable Solar Panels

Jiangsu Modern Solar Lighting Co., Ltd.

US$ 0.98 - 1.20 MOQ: 1 Watt

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

MSL

Model Number:

MSLF-120W

Payment & Shipping

Payment Methods:

Port of Shipment:

Lianyungang

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name MSL

Model Number MSLF-120W

Material Monocrystalline Silicon

Size 551*656*30mm

Number of Cells 80pcs

Max. Power 120W

Product Description

120W FOLDABLE SOLAR PANELS

Model	HYM-100W	HYM-120W	HYM-160W
Cell Type	Mono crystalline silicon solar cells
No.of cells and connections	72 *(492)*	*80 (4102)*	144 *(4182)*
Dimension of module (mm)	*63055135*	*65655135*	*83655135*
Weight	9kg	9.5kg	10.5kg
Tolerance	±3%	±3%	±3%
Open circuit voltage (voc)	21.6V	21.6V	21.9V
Optimum operation voltage vmp)	17.2V	17.2V	17.6V
Short circuit(Isc)	8.45A	8.84A	9.12A
Optimum operation current (Imp)	7.56A	7.95A	8.15A
Maximum power at STC (pm)	100Wp	120Wp	160Wp

Product Feature

The whole package will include:

A. 2 x grade A mono crystalline solar panels surrounded by a heavy duty aluminum frame
B. 1 x automatic intelligent controller with LED battery charge indicators with inbuilt circuit protection function.
C. 1 x 5 meters of color coded cable with insulated 30 amp stainless steel battery clamps
D. 1 x handle and 2 x locks attached on aluminum frame.
E. 2 x uniquely designed aluminum self locking legs
F. 1 x protective zip up carry bag
