Home > Products > galvalume steel > Aluminium Zinc Plate
Aluminium Zinc Plate
- qingdao port/tianjin port
- T/T
You May Like
Product Details
| Standard | AISI, ASTM, BS, DIN, GB, JIS, Other | Grade | CGCC CGCD SGCD DX51D | |
| Thickness | 0.14mm-1.2mm | Place of Origin | Shandong, China | |
| Brand Name | longfa | Model Number | CGCC CGCD SGCC | |
| Type | Steel Plate | Technique | Cold Rolled | |
| Surface Treatment | Coated | Application | Flange Plate | |
| Special Use | Wear Resistant Steel | Width | 800/914/1000/1200/1219/1250mm | |
| Length | 1000-6000mm |
Product Description
Specifications
aluminium zinc coilhigh quality with best price
all RAL colors
short delivery and standard export package
aluminium zinc coil of Shandong Longfa
1.Grade:SGCC,DX51D+Z
2.Thickness:0.18mm-1.2mm
3.Width:600mm-1250mm
4.ISO9001,ISO14001
1.Product Specification
1). Available Size:
Manufacturer | Thickness | Width | Inner diameter of coil | Weight of coil |
Shandong Longfa Steel PlateCo.,Ltd | 0.16-1.2mm | available from 600-1250mm Common width: 914/1000/ 1200/1219/1250mm | 508mm/610mm | 2.5-8.0tons |
2). Base plate:
Base plate | Available Zinc Coating / Alu-Zinc Coating(g/m2) |
Galvanized Steel coil | Available from 60-275g/m2 Common: 60,80, 100, 120, 160, 180,275 |
Galvalume Steel coil | Available from 30-150g/m2 Common: 30,40,50, 70, 100, 150 |
3). Available painting
Color System | Produce according to RAL Color System or as per buyer’s color sample. | ||
Painting Thickness | Top surface: 15~25microns; | ||
Bottom surface: 5~8microns. | |||
Category of Painting | Item | Code | |
Polyester | PE | ||
High-durability polyester | HDP | ||
Silicon modified polyesters | SMP | ||
Polyvinylidene fluoride | PVDF | ||
Painting structure | Top surface | Bottom surface |
|
Primer coating | No coating | 1/0 | |
Primer coating | Primer coating | 1/1 | |
Primer coating + Finish coating | No coating | 2/0 | |
Primer coating + Finish coating | Primer coating or single back coating | 2/1 | |
Primer coating + Finish coating | Primer coating + Finish back coating | 2/2 | |
4). Application
Application | Building exterior application |
Building interior application | |
Furniture | |
Household appliances | |
Steel windows | |
Others |
5). Application in the building industry
Building industry | Outdoor application | Roof, structural balcony, panels, window sills, window frames, gates, garage doors, rolling doors, booths, shutters, watch rooms, makeshift houses, street waiting room (booth), refrigerators, etc. |
Indoor application | Room doors, dividing walls, door frames, light house steel structures, sliding doors, screens, ceilings, toilets, interior elevator lobby, stairwayventilating duct, communication pipelines. |
(2)Galvalume steel coil/sheet
(3)Prepainted galvanized steel coil/sheet
(4)prepainted galvanized steel coil/sheet
(5)galvanized corrugated steel sheets
(6)prepainted corrugated steel sheets
Waiting for your inquiry!
