Specifications
Delivery shortlyLowest price to Quality product
Flexible expert service
AVAILABLE DESIGNATION OF (Prepainted galvanized steel coils) printed PPGI coils
Quality | Q/BQB 440-2003 | JIS G3312-1994 | EN 10326-2004 | ASTM A653-02a |
EN 10327-2004 | (BASE PLATE) | |||
(BASE PLATE) |
| |||
Commercial Steel | TDC51D | CGCC | DX51D+Z/AZ | CS Type A/B/C |
Forming Steel | (TSt01,TSt02,TSt03) | CGCD1 | FS Type A, Type B | |
Drawing | TDC52D /TDC53D | - | DX52D+Z/AZ | DDS TYPE A/C |
Steel | DX53D+Z/AZ | |||
Structural | TS280GD(TStE28) | CGC400 | S280D+Z/AZ | SS275 |
Steel | TS350GD(TStE34) | CGC440 | S350D+Z/AZ | SS340 Class1 |
2) OUR SPECIFICATION OF (Prepainted galvanized steel coils) printed PPGI coils
Available Size:
Manufacturer | Thickness | Width | Length of plate | Inner diameter of coil |
SHANDONG LONGFA STEEL PLATE CO., LTD | 0.2-1.2mm | 800/914/1000/1200/1219/1250mm | 1000-6000mm | 508mm/610mm |
Coated Mass OF (Prepainted galvanized steel coils) printed PPGI coils:1.2
Base plate | Available Coated Mass(g/m^2) |
Galvanized Steel | 80, 100, 120, 160, 180 |
Galvalume Steel | 50, 70, 150 |
Available Painting OF (Prepainted galvanized steel coils) printed PPGI coils:
Category of Painting | Item | Code | |
Polyester | PE | ||
High-durability polyester | HDP | ||
Silicon modified polyesters | SMP | ||
Polyvinylidene fluoride | PVDF | ||
Easy-Cleaning | — | ||
Painting Thickness | Top side: 20+5microns; | ||
Bottom side: 5~7microns. | |||
Color System | Produce according to RAL Color System or as per buyer’s color sample. | ||
Painting structure | Top surface | Bottom surface |
|
Primer coating | No coating | 1/0 | |
Primer coating | Primer coating | 1/1 | |
Primer coating + Finish coating | No coating | 2/0 | |
Primer coating + Finish coating | Primer coating or single back coating | 2/1 | |
Primer coating + Finish coating | Primer coating + Finish back coating | 2/2 | |
We have the equipment advanced:
1.High quality: GB3091--84, BA1387--87 standards.
2.High production efficiency :double into double out type , the annual output 3--4 million tons
3.A high degree of automation: system adopts PC program control , equipped with frequency conversion.
4.Low production cost: the use of advanced help plating agent , ensure solvent except iron technology of iron content 2 price is less than 0.6g/liter long-term ,this technology will tons product normal zinc consumption reduce 5--10 kilograms . Using coal gas as fuel can day endowment 200 yuan/ton product.
5.zinc pot with long service life :the reflection wall heating pot body heated evenly and corrosion slowed.
Looking forward to your purchase
