Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > RB03 Casting Robot

RB03 Casting Robot

US$ 3,000 - 30,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Other

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Dalian R&C Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

dalian

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Other

CNC or Not CNC

Automatic Grade Automatic

Place of Origin Liaoning, China

Brand Name R&C

Model Number RB03

Voltage 220V/380V

Power(W) 3KW

Weight 125kg

Certification ISO9001,CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

casting robot
ISO9001 Quality System

RB03 RB03 casting robot

1. Machine Tool Introduction:

Automatic Welding

Automatic casting

Ultra-bearing super bearing turntable 70kg

Feeding the fastest speed one second place

Actual production operating speed 2M / sec

2. The main technical parameters (standard):

Item		RB03			RB08		RB20	RB50
Degree of Freedom		6			6		6	6
Drive System		AC servo motor			AC servo motor		AC servo motor	AC servo motor
Maximum Load Capacity		+0.05mm			+0.05mm		+0.05mm	+0.05mm
Movement Range	J1 Axis	+170°			+170°		+170°	+170°
	J2 Axis	+150° ~- 60°			+120° ~- 85°		+133°~- 95°	+130 °~- 90°
	J3 Axis	+75° ~- 170°			+85°~-170°		+76° ~- 166°	+280° ~- 160°
	J4Axis	+190°			+180°		+180°	+360°
	J5Axis	+125°			+135°		+133°	+120°
	J6Axis	+360°			+360°		+360°	+360°
Rated Speed	J1 Axis	2.62rad/s, 150° /s			2.09rad/s, 120° /s		1.90rad/s, 109° /s	1.23rad/s, 70° /s
	J2Axis	2.62rad/s, 150° /s			2.09rad/s, 120° /s		1.30rad/s, 74.5° /s	1.12rad/s, 64° /s
	J3xis	3.14rad/s, 180° /s			2.09rad/s, 120° /s		1.74rad/s, 100° /s	0.90rad/s, 51° /s
	J4Axis	4.71rad/s 270° /s			3.93rad/s, 225° /s		3.93rad/s, 225° /s	2.51rad/s, 144° /s
	J5Axis	4.71rad/s 270° /s			2.53rad/s, 145° /s		2.56rad/s, 147° /s	2.92rad/s, 167° /s
		4.71rad/s 270° /s			5.24rad/s, 300° /s		5.16rad/s, 296° /s	5.10rad/s, 292° /s
	J6Axis
Environmental Condition	Temperature	0--45°C
	Humidity	20~80% 20~80%(no condensation)

	Other		Keep away from flammable, explosive and corrosive gases and liquid. Avoid water, oil and dust. Be far away from electric appliance noise source(plasma)
Installation Posture			Installed on floor
Robot Body weight			125kg
Electric Cabinet weight			75kg	180kg		245kg			600kg

3.Our Product Photo:

4. Other robot you may interest in:

5.Company Introduction:

We are the big machine manufacturer specializing in producing heavy duty machine tools, it has five factories in China which mainly produce Vertical Lathe, Boring & Milling Machine, Heavy-duty Horizontal Lathe, both conventional and CNC types.

We have a group of professional engineers in charge of technology, manufacturing, installing and testing, so we can guarantee that our machines will put on good performance based on high quality. We can provide customers with full service and technical consultation upon different requests in 24 hours. R&C Machinery would like to offer its best machines with best solution, and build itself as the bridge and window for both overseas and domestic enterprises and customers.

6. Main Export Market:

Canada, the U.S.A., Italy, France, Brazil, Bolivia, Chile, Russia, Romania, Saudi Arabia, Syria, Jordan, the U.A.E., Indonesia, Singapore, Thailand, India, Pakistan, South Africa, Egypt, Nigeria, Kenya and so on.

7. Our Work Shop:

8. With Customers:

9. Why Choose Us:

10. After-sales Service and Commitment to Quality:

a. The date of final acceptance of the machine, the vendor of the product free of charge three packs a year (the buyer causes damage will be charged the cost of).

b. Machine fails, the user information of the seller can accurately determine the cause of the malfunction and treatment measures, given immediately reply sent to the scene to deal with such as could not determine the cause, within 48 hours, to solve the failure so far.
