Dalian R&C Machinery Co., Ltd.: Dalian, Liaoning, China; Main products: CNC Lathe, Machine Center, CNC Milling Machine, Industrial Robot, Machine Equipment CNC Lathe, Vertical Lathe, Boring and Milling Machine, Pipe threading lathe

Home > Products > Vertical Lathe Machine > CK5250 5-meter Dalian heavy duty vertical lathe

CK5250 5-meter Dalian heavy duty vertical lathe

FOB Price

USD $353,500 - $375,000 / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port DALIAN
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Vertical
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	5000mm	Place of Origin	Liaoning, China
Brand Name	R&C	Model Number	CK5250
Voltage	380V,60HZ	Power(W)	DC75(kw)
Dimension(LWH)	935064007200mm	Weight	90 t
Certification	ISO9001 & CE	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

1.Siemens828D
2.Table diameter 4500mm
3.Max. turning diameter 5000mm
4.The max height of workpiece3150mm

CK5250 5-meter Dalian heavy duty vertical lathe

IMAGES>SPECIFICATION>SHOW ROOM>OTHER VERTICAL LATHES>OTHER MACHINES>PACKING>R&C

CNC SYSTEM IS SIEMENS828D.

The customer can choose other systems.

SPECIFICATION

Parameters	Unit	CK5250
Max. turning diameter	mm	5000
Diameter of working table	mm	4500
Workbench speed series		stepless
Max. height of work piece	mm	3150
Max. weight of work piece	t	50
Workbench speed range	r/min	0.42~42
Vertical tool rest level travel	mm	2765
Vertical tool rest vertical travel	mm	1600
The motor power	KW	75
Overall size	mm	935064007200
Machine weight(app.)	t	90
CNC SYSTEM		SIEMENS828D

Optional Parts: Cooling system, protection cover,

4 position vertical tool post, 6 position vertical tool post etc.

SHOW ROOM

OTHER VERTICAL LATHES

C51 SERIES

MANUAL SINGLE COLUMN

C52 SERIES MANUAL DOUBLE COLUMN

CK51 SERIES

CNC SINGLE COLUMN

CK52 SERIES

CNC DOUBLE COLUMN

Please click above photos to know more vertical lathes.

OTHER MACHINES

PACKING>> R&C
