DL25M 10000rpm High Speed CNC Vertical Machining Center

DL25M 10000rpm High Speed CNC Vertical Machining Center photo-1
DL25M 10000rpm High Speed CNC Vertical Machining Center photo-2
DL25M 10000rpm High Speed CNC Vertical Machining Center photo-3
DL25M 10000rpm High Speed CNC Vertical Machining Center photo-4
DL25M 10000rpm High Speed CNC Vertical Machining Center photo-5
DL25M 10000rpm High Speed CNC Vertical Machining Center photo-6
US$ 35,000 - 55,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Vertical
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Vertical
Place of Origin Jiangsu, China
Brand Name R&C
Model Number VM850H
Voltage 380V
Power(W) 5.5-7.5KW
Weight 5800KG
Certification CE ISO BV
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

VM850H 10000rpm High Speed CNC

Vertical Machining Center







Photos of Machine
DL25M 10000rpm High Speed CNC Vertical Machining Center
DL25M 10000rpm High Speed CNC Vertical Machining Center
DL25M 10000rpm High Speed CNC Vertical Machining Center
DL25M 10000rpm High Speed CNC Vertical Machining Center
Main Parameters

item

   VM850H

unit

Travel

X axis travel

800

mm

Y axis travel

500

mm

Z axis travel

500

mm

Distance from spindle nose to table surface

110-610

mm

Table

Size

500×1050

mm

T-slots

3-18*130

mm

Max. loading capacity

400

kg

Spindle

Spindle taper

BT40



Spindle speed

10000

rpm

Spindle motor power

7.5

kw

Automatic tool changer

Tool capacity

24

pieces

Tool Change type

Vertical



Tool holder type

BT40



Feed rate

Rapid traverse (X/Y axis)

48000

mm/min

Rapid traverse (Z axis)

36000

mm/min

Cutting Feed rate

1-10000

mm/min

Accuracy

Repeatability

0.005

mm

positioning accuracy

0.01

mm

Others

CNC system

FANUC 0I MATE MD



Lubrication system

Auto



Cooling system

Water cooling



Spindle oil cooling

Oil cooling



Specification of X/Y/Z axis

Linear rail

HIWIN

X/Y/Z bearing

NSK

Japan

Overall dimension

2795×2200×2270

mm

Machine weight(abt)

4300

kg
