VM1050 3 Axis CNC Vertical Machining Center Price

FOB Price

USD $39,217 - $47,500 / Set

1 Set(Min.Order)

Product Details

Condition:	New	Type:	Vertical	Place of Origin:	Liaoning, China
Brand Name:	R&C	Model Number:	VM1050	Voltage:	380V
Power(W):	5.5-7.5	Dimension(LWH):	TALK MORE	Weight:	6.5t
Certification:	CE	Warranty:	1 year	After-sales Service Provided:	Engineers available to service machinery overseas

1.Table size 450(500)*1000
2.X/Y/Z travel 1000/500/500
3.Max load 800
4. Tool magazine 16/24
5.Ballscrew bearing NSK

VM1050 3 Axis CNC Vertical Machining Center Price

IMAGE >> SPECIFICATION >> MAIN PARTS >> OTHER 5AXIS >> OTHER MACHINES >> PACKING >> R&C

SPECIFICATION

tem		VM1050	unit
Travel	X axis travel	1000	mm
	Y axis travel	500	mm
	Z axis travel	500	mm
	Distance from spindle nose to table surface	150-650	mm
	Distance from spindle center to vertical column rail	530	mm
Table	Size	450(500)×1000	mm
Table	Max. loading capacity	800	kg
Spindle	Spindle taper	BT40
	Spindle speed	8000	rpm
	Spindle motor power	5.5-7.5	kw
Automatic tool changer	Tool capacity	16/24	pieces
Feed rate	Rapid traverse	≥20000	mm/min
Ball screw		HIWIN
Coupling		KTR
Accuracy	Repeatability	0.005	mm
Accuracy	Positioning accuracy	0.01	mm
Dimension	CNC system	KENYO/GSK/FAGOR /SIEMENS/FANUC
Dimension	Machine weight(abt)	6500

MAIN PARTS

OTHER MILLING MACHINE OR VMC

OTHER MACHINES

PACKING

R&C

OR YOU CAN TOUCH WITH BLANCHE LIU

TEL:86+18742070473 SKYPE: rc-machinery011
