Z30125 drilling machine

FOB Price

USD $5,000 - $10,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	Normal
Drilling Speed	800r/min	Place of Origin	Liaoning, China
Brand Name	R&C	Model Number	Z30125
Voltage	320v	Power(W)	18.5KW
Dimension(LWH)	5817X2000X5120mm	Weight	28500kg
Certification	ISO9001,CE	After-sales Service Provided	Engineers available to service machinery overseas

IMAGE >> SPECIFICATION >> MAIN PARTS >> OTHER 5AXIS >> OTHER MACHINES >> PACKING >> R&C

IMAGE > SPECIFICATION>MAIN PARTS > OTHER 5AXIS>PACKING>OTHER MACHINES> PACKING > R&C

Item		Unit	z30125×40
Max. drilling diameter		mm	125
Distance from spindle center to column surface	Max.	mm	4000
Distance from spindle center to column surface	Min.	mm	600
Distance from spindle nose to base surface	Max.	mm	2500
Distance from spindle nose to base surface	Min.	mm	750
Spindle travel		mm	560
Taper of spindle bore (Morse)		No	Metric80
Spindle speed		r/min	6.3-800
Spindle speed series			16
Spindle feed rate series		mm/r	0.06-3.2
Table size		mm	800×1250
Headstock horizontal distance		mm	3400
Main power		kw	18.5
Weight	Net	Kg	28500
Weight	Gross	Kg	31500
Dimensions	L	mm	5817
	W	Mm	2000
	H	mm	5120
