HST Series Two Coils Hot Water Tank

Specifications

1.Size from 300l to 500l
2.Two coils structure are available for heat pump and solar connection
3.Electric heater is optional



HST Series Two Coils Water Tank

Keram HST Series hot water tanks are developed especially for the increasingly popular heat pump. The large heating surface of the heating coil and its sophisticated diabolo-shape enable a very efficient hot water production, which guarantees a quick reheat time and a high hot water performance. The high-quality insulation reduces heat loss, which minimizes the costs for a high hot water performance. The two coils structure inside makes the water tank can be connected both heat pump and solar. A combination of a more efficient system saves more energy consumption.



Product Feature

•	High efficient stainless coil heat exchanger inside
•	12kgs pressure durable
•	50mm thick polyurethane foam insulation layer
•	Size from 300l to 500l
•	Two coils structure are available for heat pump and solar connection
•	Electric heater is optional
•	Anti-corrosion magnesium anode fixed











Technical specifications for HST Series water tank





technical data		500 L
Volume	l	500
Weight	kg	91
Max. working pressure tank	bar	10
Max. working pressure coil	bar	40
Max. working temperature tank	°C	95
Insulation		EPS
	mm	50
Heat loss DIN 44532	kWh/24h	3,20
Heating coil
Heating surface	m2	3,7
Continuous capacity DIN 4708	kW	52/62
Continuous capacity 10-45°C	l/h	1284/1530
Hot water flow	m3/h	2/3
Pressure loss	mbar	165/342
Heating coil (extra)
Heating surface	m2	0,75
Continuous capacity 50°C tank temperature and 60°C from boiler supply in and ΔT = 5°C	kW	17,0
Hot water capacity 10-45°C	l/h	258
Hot water flow	m3/h	0,24
Pressure loss	mbar	2
Heating coil Solar	m2	0,75
Continuous capacity 80°C DIN 4708	kW	10,5
Hot water capacity 10-45°C	l/h	258
Hot water flow	m3/h	0,24
Pressure loss	mbar	2





	HST 500 L	Silver	HST 500
	Part:
A	Cold water inlet	R	1"
B	To boiler return	R	1½"
C	From boiler supply	R	1½"
D	Immersion heater	G	1½"
E	Circulation	Rp	1/2"
F	Hot water outlet	R	1"
G	Upper thermostat	G	3/4"
H	Lower thermostat	G	3/4"
I	Thermometer	G	1/2"
J	Clean out cover	mm	80,5 x 95
K	solar water inlet	R	3/4"
L	solar water outlet	R	3/4"
M	Circulation	G	1/2"
	Height insulation incl.	mm	1541
	Tilting height excl. insulation	mm	1680
	Diameter insulation excl.	mm	635
	Diameter insulation incl.	mm	735
