US$ 500 - 510 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HaiSheng
Model Number:
HS-4806
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name HaiSheng
Model Number HS-4806
Usage Stripping

Coaxial Stripping Machine





Features:



Mainly used for processing coaxial cable and special single line, adopt the most advanced rotating turret to improve the accuracy and speed.



Using specific devices and rotary tool axis positioning mode,up to peeling 9 layer,processing of various sizes and sheath wire with no blade change,And the controller of modular equipment can be freely set , cutting diameter digital display.



Technical parameters:



Model

HS-4806 (Precision)

Max cable diameter

0.81-up to 7.99 mm

Cutting Unit Depth

0.01mm

Max Stripping Length

48mm

Max Stripping layers

9 layers

Drive mode

Motor / ball screw drive(Japan imports)

Display method

Touch screen

Blade/Material

2pcs/Tungsten steel

Centering piece/Material

2pcs/Tungsten steel

Clamp devices

Self-aligning, motor drive, the clamping force control program

Productivity

500-700pcs/h(Depending on the length and types of cable )

Boot mode

Manual / Sensor

Supply power

220V/50HZ

Rated power

380W

Weight

19KG

Dimensions

525X186X278 mm

Working environment

0-50 degrees, moderate drying, vibration-free work surface, moderate dryness workshop



  Product Display:

Coaxial Stripping Machine

Coaxial Stripping Machine

Coaxial Stripping Machine

Coaxial Stripping Machine



Our Services



---Purchase guidance

If you are not sure which model is the best option within you budget, please send us the parameter or wire, it’s our pleasure to make a recommendation and comparison models to you.



--- Technical Support

In some cases, professional technical support will be needed , such as parameter meter set-up for difficult-to process wires. HS engineers are here for your assistance.



---After Sale Service

Don’t worry, we are here to help. HS provides life time after sale support to our customers including operation guidance, parts replacement, maintainance support. Just feel free to contact us!



---OEM

HS provides OEM services to our customers.





FAQ:

If u have any question, u can feel free to contact me
